17/96 Circuit-breakers, switch-disconnectors
Terminals
2010 CA08103002Z-EN
Terminals
Space requirement Rated
current1) Number
of poles
For use
with
Terminal capacity Terminal capacity
Cable
Cable
lugs
Terminal
capacity
AWG/kcmil Copper strip
No. of discs ×
width × disc
thickness
Copper bar
width x
thickness
In
A mm² mm mm
Screw terminals
Threaded stud
standard
equipment
2-hole Max.
1600
3 and 4
pole
NZM4(-4)
N4(-4)
N(S)4
Copper
cable lugs
1 x 120-185
4 x 50-185
1 x 250-350
4 x 0-350
(2 x)
10 x 50 x 1.0
(2 x) 50 x 10
Screws
3 pole NZM4,
N(S)4
4 pole NZM4-4,
N4-4
Module plate
1-hole – Max.
1250
3 pole NZM4,
N(S)4
Copper
cable lugs
1 x 120-300
2 x 95-300
1 x 250-600
2 x 000-600
(2 x)
10 x 40 x 1.0
(2 x)
10 x 50 x 1.0
(2 x) 40 x 10
(2 x) 50 x 10
4 pole NZM4-4,
N4-4
2-hole – Max.
1400
3 pole NZM4,
N(S)4
2 x 95-185
4 x 35-185
2 x 000-350
4 x 2-350
(2 x)
10 x 50 x 1.0
(2 x) 50 x 10
4 pole NZM4-4,
N4-4
2-hole – Max.
1250
3 pole NZM4,
N(S)4
Copper
cable lugs
2 x 95-300 2 x 000-600 (2 x)
10 x 40 x 1.0
(2 x)
10 x 50 x 1.0
(2 x) 40 x 10
(2 x) 50 x 10
4 pole NZM4-4,
N4-4
– Max.
1600
3 pole NZM4,
N(S)4
4 pole NZM4-4,
N4-4
25
50
20
o10.5 o 10.5
NZM4 HPL17096EN
