189 / 543
2010 CA08103002Z-EN
www.eaton.comCircuit-breakers, switch-disconnectors
Terminals
–
NZM3-XK300
100782
1 set
Contains parts for a terminal located at
top or bottom for 3 or 4 pole switches.
Only in combination with connection
width extension NZM3(-4)-XKV70.
Use ferrules with flexible and highly
flexible conductors.
With control cable terminal for
1 × 0.75 – 2.5 mm
2
or 2 × 0.75 – 1.5 mm
2
copper conductor as standard.
Product Standards UL489; CSA-C22.2
No. 5-09; IEC60947,
CE marking
UL File No.
E31593
UL CCN
DIHS
CSA File No.
022086
CSA Class No.
1432-01
NA Certification
UL Listed,
CSA certified
Suitable for
Refer to main com-
ponent information
–
NZM3-4-XK300
100783
1 set
–
–
NZM3-XK22X21
100784
1 set
–
–
NZM3-4-XK22X21
100785
1 set
–
NZM3-XKA1
2)
271459
1 set
Contains parts for a terminal located at
top or bottom for 3 or 4 pole circuit-
breakers.
With control cable terminal for
1 × 0.75 – 2.5 mm
2
(18 – 14 AWG) or
2 × 0.75 – 1.5 mm
2
(18 – 16 AWG) copper
cable as standard.
Fitting outside switch housing.
Use ferrules with flexible and highly
flexible conductors. Max. cross section
shown can only be connected when
flexible and without ferrules.
Cover NZM3(-4)-XKSA must be fitted
(included as standard).
–
–
NZM3-4-XKA1
2)
271460
1 set
–
NZM3-XKA2
271461
1 set
Product StandardsUL489; CSA-C22.2
No. 5-09; IEC60947,
CE marking
UL File No.
E31593
UL CCN
DIHS
CSA File No.
022086
CSA Class No.
1432-01
NA Certification UL Listed, CSA certified
Suitable for
Refer to main compo-
nent information
–
NZM3-4-XKA2
271462
1 set
–
+NZM3-XKRO
266790
NZM3-XKR
266792
1 set
Part no. suffix and part no.contain parts
for a circuit-breaker side at top or bottom
for 3 or 4 pole switches.
O = for fitting at the top
U = for fitting at the bottom
–
+NZM3-XKRU
266791
–
1 set
+NZM3-4-XKRO
266793
NZM3-4-XKR
266795
1 set
+NZM3-4-XKRU
266794
–
1 set
–
–
NZM3/4-XSTS
266797
1 set
Contains for two terminal locations located
at top or bottom for 3 or 4 pole circuit-
breakers.
Included as standard with tunnel terminal.
Degree of protection IP1X
Height or thickness of connections: 2 mm
Product StandardsUL489; CSA-C22.2
No. 5-09; IEC60947,
CE marking
UL File No.
E140305
UL CCN
DIHS
CSA File No.
022086
CSA Class No.
1437-01
NA Certification UL Listed, CSA certified
Suitable for
Refer to main compo-
nent information
–
–
NZM-XSTK
266739
1 set
Contains for two terminal locations located
at top or bottom for 3 or 4 pole circuit-
breakers.
Included as standard with tunnel terminal.
Degree of protection IP1X
NZM-XSTK cannot be combined with
NZM1(-4)-XIPK IP2X protection against
contact with a finger.
Height or thickness of connections: 2 mm
Part no. suffix
Article no. for
ordering with
basic device
Price
See price
list
Part no.
Article no.
when ordered
separately
Price
See price
list
Std. pack
Notes
Information relevant for export to
North America
17/93
NZM3
HPL17093EN
