www.eaton.comCircuit-breakers, switch-disconnectors
Terminals
Notes
Information relevant for export to North America
Contains parts for a terminal located at top or bottom for 3 or 4 pole switches.
Contact protection where cable lugs are used on screw terminals
.
When using insulated conductor material, degree of protection IP2X.
UL/CSA certification not required
–
Contains parts for a terminal located at top or bottom for 3 or 4 pole switches.
Insulation/protection against direct contact where cable lugs, bars or tunnel terminals are used.
Included in set with tunnel terminals.
When using insulated conductor material to degree of protection IP1X.
Product Standards UL489; CSA-C22.2 No. 5-09; IEC60947,
CE marking
UL File No.
E31593
UL CCN
DIHS
CSA File No.
022086
CSA Class No.
1437-01
NA Certification
UL Listed, CSA certified
Suitable for
Refer to main component information
–
Contains parts, including insulating plate for mounting plate, for a terminal located at top or bottom for
3 or 4 pole circuit-breakers.
Included with the connection width extension.
Cannot be combined with the NZM3(-4)-XKA tunnel terminal, NZM3(-4)-XKR connection on rear.
Insulation protection where cable lugs, bars, or flat conductor are used.
Product Standards UL489; CSA-C22.2 No. 5-09; IEC60947,
CE marking
UL File No.
E31593
UL CCN
DIHS
CSA File No.
022086
CSA Class No.
1432-01
NA Certification
UL Listed, CSA certified
Suitable for
Refer to main component information
Contains parts for a terminal located at top or bottom for 3 or 4 pole switches.
Enhanced contact protection (simplified finger protection).
UL/CSA certification not required
–
Contains parts for a terminal located at top or bottom for 3 pole circuit-breakers.
Insulation protection/protection against direct contact for connection of cable lugs or bars to connection
width extension.
Can also be used fir connection width extension NZM3-XKV70 with terminals NZM3-XK300, NZM3-XK22x21
or NZM4-XKA.
When using insulated conductor material, degree of protection IP2X.
–
Contains parts for a terminal located at top or bottom for 3 or 4 pole circuit-breakers.
Enhanced contact protection to IP2X.
Protection when reaching into the cable connection area with the connection of cables in the box terminal.
with 2 conductors max. cross section 70 mm
2
.
Cannot be combined with NZM-XSTK control circuit terminal.
UL/CSA certification not required
–
Contains parts for a terminal located at top or bottom for 3 or 4 pole switches.
Enhanced contact protection to IP2X.
When fitting to NZM3...-(C)NA or N3...-NA:
with 2 conductors max. cross section 70 mm
2
.
UL/CSA certification not required
–
The part no. contains a cable lug for 3 or 4 pole switch.
Special cable lug, narrow style
–
–
17/95
NZM3
HPL17095EN
