Eaton Industrial Switchgear - XEnergy XPole Energy distribution, switching and protection

186 / 543

17/90 Circuit-breakers, switch-disconnectors
Terminals
2010 CA08103002Z-EN
Terminals
Max. cable
connection area
Number
of poles
For use with Rated
current1) Terminal capacity Terminal capacity
Cable
Cable lugs
Terminal
capacities1) AWG/kcmil Copper strip
No. of discs ×
width × disc
thickness
Copper bar
width x
thickness In
A mm² mm mm
Box terminal
3 pole NZM3(-4),
PN3(-4),
N(S)3(-4)
max. 500
400 UL/
CSA
Copper cable
Copper cable
1 x 35 - 240
2 x 16 - 120
1 x 2 - 350 min. 6 x 16 x 0.8
max. 10 x 24 x 1.0
or
max. 11 x 21 x 1
–
630 Copper cable 1 x 35 - 240
2 x 16 - 120
1 x 2 - 350 10 x 24 x 1.0
+ 5 x 24 x 1.0
or
(2 x) 8 x 24 x 1.0
4 pole
Screw connection, standard
3 pole NZM3,
PN3,
N(S)3
630
Max. 400
Copper cable
lugs
Aluminiumcable
lugs
1 x 16 - 300
2 x 16 - 240
1 x 10 - 120
2 x 10 - 120
1 x 4 - 350
2 x 350
1 x 4 - 350
2 x 350
10 x 32 x 1.0
+ 5 x 32 x 1.0
30 x 10
+ 30 x 5
4 pole NZM3-4,
PN3-4,
N(S)3-4
Connection width extension
One hole, for screws or terminals
3 pole NZM3,
PN3,
N(S)3
630 Copper cable
lugs
Aluminiumcable
lugs
2 x 300 2 x 500 (2 x) 10 x 50 x 1.0 (2 x) 10 x 50
4 pole NZM3-4,
PN3-4,
N3-4
Two holes, for screws or terminals
– 3 pole NZM3, PN3,
N(S)3
630 Copper cable
lugs
NZM3-
XKV70-2:
4 x 35 - 185
NZM3-
XKV70-2 +
NZM4-XKA:
4 x 50 - 240
NZM3-
XKV70-2:
2 x 350
NZM3-
XKV70-2 +
NZM4-
XKA:
4 x 500
NZM3-XKV70-2 +
NZM4-XKB:
≧ 6 x 16 - 0.8
≦ (2 x) 10 x 32 x 1
(2 x) 10 x 50
4 pole NZM3-4,
PN3-4,
N3-4
One threaded stud
– 3 pole NZM3, PN3,
N(S)3
630 Copper cable
lugs
2 x 95-300 2 x 500 (2x) 10 x 32 x 1.0 (2 x) 10 x 40
16
25
15
o 10.5
32
NZM3 HPL17090EN
