187 / 543
2010 CA08103002Z-EN
www.eaton.comCircuit-breakers, switch-disconnectors
Terminals
Part no. suffix
Article no. for
ordering with
basic device
Price
See price
list
Part no.
Article no.
when ordered
separately
Price
See price
list
Std. pack
Notes
Information relevant for export to
North America
+NZM3-XKCO
262246
NZM3-XKC
260042
1 set
Part no. suffix and part no.contain parts
for a circuit-breaker side at top or bottom
for 3 or 4 pole switches.
Conversion kit for circuit-breaker with
screw terminal.
Fitted within the switch housing.
O = for fitting at the top
U = for fitting at the bottom
U
e
≧ 525 V AC:
Use NZM3(-4)-XKSA cover.
Use ferrules with flexible and highly
flexible conductors. Observe limited
cable cross-section through sleeve.
Product Standards UL489; CSA-C22.2
No. 5-09; IEC60947,
CE marking
UL File No.
E31593
UL CCN
DIHS
CSA File No.
022086
CSA Class No.
1437-01
NA Certification
UL Listed,
CSA certified
Suitable for
Refer to main com-
ponent information
+NZM3-XKCU
262245
–
+NZM3-4-XKCO
266781
NZM3-4-XKC
266783
1 set
–
+NZM3-4-XKCU
266782
–
–
–
NZM3-XKS
260039
1 set
Contains parts for a terminal located at
top or bottom for 3 or 4 pole switches.
Standard connection with all NZM3, PN3
and N3 circuit-breakers.
Conversion kit for circuit-breaker with
box terminal.
Use special cable lugs narrow version,
￫17/88
Fitted within the switch housing.
If a bar is used, insulation (400 mm)
heat-shrink tubing and a cover
NZM3(-4)-XKSA are required.
U
e
≧ 525 V AC:
For all other connection types use cover
NZM3(-4)-XKSA.
Product Standards UL489; CSA-C22.2
No. 5-09; IEC60947,
CE marking
UL File No.
E31593
UL CCN
DIHS
CSA File No.
022086
CSA Class No.
1437-01
NA Certification
UL Listed,
CSA certified
Suitable for
Refer to main com-
ponent information
–
–
NZM3-4-XKS
266780
1 set
–
–
–
NZM3-XKV70
100514
1 set
Contains parts for a terminal located at
top or bottom for 3 or 4 pole switches.
Central drilling for e.g. up to 2 cable lugs
per phase.
For fitting to switches with screw
terminal.
Phase isolator and insulation plate are
included as standard.
Distance between pole centres with
NZM3(-4)-XKV70: 70 mm
Hole for control wire exists.
Connection terminals NZM3(‐4)‐XK300
and NZM3(-4)‐XK22X21 can be installed.
Product Standards UL489; CSA-C22.2
No. 5-09; IEC60947,
CE marking
UL File No.
E140305
UL CCN
DIHS
CSA File No.
022086
CSA Class No.
1432-01
NA Certification
UL Listed,
CSA certified
–
–
NZM3-4-XKV70
100515
1 set
–
–
–
NZM3-XKV70-2
119860
1 set
Contains parts for a terminal located at
top or bottom for 3 pole circuit-breakers.
Double hole fitting for up to four 185 mm
2
cable lugs, 50 mm bbar or large flat cable
terminal NZM4-XKB or large tunnel
terminal NZM4-XKA
For fitting to switches with screw
terminal.
Phase isolator, insulation plate and
2 control circuit terminals supplied.
Product Standards UL489; CSA-C22.2
No. 5-09; IEC60947,
CE marking
NA Certification
Request filed for UL
and CSA
Suitable for
Refer to main com-
ponent information
–
–
NZM3-4-XKV70-2
132673
–
–
NZM3-XKV70KB
112884
1 set
Contains parts for a terminal located at
top or bottom for 3 pole circuit-breakers.
Threaded stud for cable lugs up to
2 × 300 mm
2
For fitting to switches with screw
terminal.
Phase isolator, insulation plate and
2 control circuit terminals supplied.
–
17/91
NZM3
HPL17091EN
