Eaton Industrial Switchgear - XEnergy XPole Energy distribution, switching and protection

203 / 543

2010 CA08103002Z-EN
Circuit-breakers, switch-disconnectors
Auxiliary contacts with screw terminals/spring-cage terminal
Part no.
Article no.
when ordered
separately
Price
See price
list
Std. pack Notes Notes
M22-CK10
216384
20 off The following applies
for the std. pack:
M22-(C)K… :
Std. pack = 20 off
The following can be clipped into the switch:
• NZM1: one standard auxiliary contact
• NZM2: up to two standard auxiliary contacts M22-(C)K...
• NZM3: up to three standard auxiliary contacts M22-(C)K...
• NZM4: up to three standard auxiliary contacts M22-(C)K...
Any combinations of the auxiliary contact types are possible.
Marking on switch: HIN
On combination with remote operator NZM-XR... the right mounting location of
standard auxiliary contact HIN can be fitted only with individual contacts.
M22-CK01
216385
M22-CK11
107940
M22-CK02
107899
M22-CK20
107898
Not in conjunction with undervoltage release NZM…-XU… or shunt release
NZM…-XA…
Early make with switch on and switch off (manual actuation): approx. 20 ms
Not in conjunction with undervoltage release NZM…-XU…, shunt release
NZM…-XA… or remote operator NZM…-XR…
Early make (manual operation): approx. 20...90 ms
M22-CK10
216384
20 off The following applies
for the std. pack:
M22-(C)K… :
Std. pack = 20 off
The following can be clipped into the switch:
• NZM1 - one trip-indicating auxiliary switch
• NZM2 - one trip-indicating auxiliary switch M22-(C)K…
• NZM3 - one trip-indicating auxiliary switch M22-(C)K…
• NZM4 ‐ up to two trip-indicating auxiliary switches M22‐(C)K.…
Any combinations of the auxiliary contact types are possible.
Not in combination with switch-disconnector PN…
Marking on switch: HIA
Labeling in residual-current block: HIAFI.
If the trip-indicating auxiliary contacts are used in the residual-current block,
the NC contacts operates as N/O contacts and the N/O contact operates as an
NC contact.
M22-CK01
216385
20 off
M22-CK11
107940
20 off
M22-CK02
107899
20 off
M22-CK20
107898
20 off
2) Product Standards UL489; CSA-C22.2 No. 5-09; IEC60947, CE marking
UL File No. E140305
UL CCN DIHS
CSA File No. 022086
CSA Class No. 1437-01
NA Certification UL Listed, CSA certified
17/107
NZM1, M22-... HPL17107EN
