14/116 Automation products
Digital output modules
Remote I/O XI/ON
2010 CA08103002Z-EN
Remote I/OXI/ONDigitaloutputmodules
XN-2DO-24VDC-0.5A-P XN-2DO-24VDC-0.5A-N XN-2DO-120/230VAC-0.5A
Digital output modules
Channels Number 2 2 2
Rated voltage at supply terminal UL 24 V DC 24 V DC 120/230 V AC (45 - 65 Hz)
Rated current drawn from supply terminal
(for 0 mA load current)1)
IL mA ≦ 20 ≦ 20
Rated current drawn from module bus 2) IMB mA ≦ 32 ≦ 32 ≦ 35
Insulation test Ui V AC 500 500 1500
Heat dissipation W Normally 1 Normally 1 Normally 1
Output voltage
High level > U L - 1 V DC < GNDL + 1 V DC > U L - 2 V AC, (zero-point
switching triac)
Output current A
High level (rated) A 0.5 0.5 0.53)
High level (permissible range) A < 0.6 < 0.6 0.02 - 0.5
Low level mA < 1.5
Back-up fuse 500 mA FF
Surge current IS A 8 (1 period at 60 Hz)
Number of parallel-switchable outputs max.
Total module current A 1 1 1
Delay for signal changeover, resistive load
From Low to High level μs < 100 < 100 < T/2 + 1 ms
From High to Low level μs < 100 < 100 < T/2 + 1 ms
Load resistance range > 48 Ω At 120 V AC:
240 Ω - 6 kΩ
At 230 V AC:
460 Ω - 11.5 kΩ
Utilization factor % g 100 100 100 (observe derating)
The following can be connected: Resistive loads
Inductive loads
Lamp loads
Resistive loads
Inductive loads
Lamp loads
Resistive loads
Inductive loads
Lamp loads
Resistive load Ω > 48 > 48
Inductive load H < 1.2 < 1.2
Lamp load RLL W < 3 < 12
Switching frequency
For resistive load f Hz < 5000 (RLO < 1 kΩ) < 100 (RLO < 1 kΩ)
For inductive load Hz < 2 < 2
For lamps Hz < 10 < 10
Number of diagnostic bits 2 2
Diagnostics Yes Yes No
Outputs to EN 61131-1 Protected Protected
Retriggering after elimination of short circuit Ii Self-acting Self-acting
Basic modules
With C connection XN-S3...-SBC
XN-S4...-SBCS
XN-S3...-SBC
XN-S4...-SBCS
XN-S3...-SBC
XN-S4...-SBCS
Notes 1) The supply terminal (UL) provides power for the module electronics and for the
consumers at the outputs. The total current required for each module consists of
the sum of all partial currents.
2) Part of the XI/ON module’s electronics is supplied with module bus voltage (5 V DC),
the other part through the supply terminal (UL).
3) To increase the maximum output current to up to 1 A, two outputs can be connected
in parallel.
