Remote I/OXI/ONGenerl information, terminals
Technical data
General
Standards
EN 61000-6-2, EN 61000-6-4, EN 61131-2
Supported fieldbus systems
PROFIBUS-DP, CANopen, DeviceNet, Ethernet (depending on gateway)
Potential isolation
Yes, through optocoupler
Ambient temperature
°C
0 - 55
Ambient temperature, storage
°C
-25 -
+85
Relative humidity
%
5 – 95 (
indoor), Level RH-2, non-condensing (for storage at 45°C)
Harmful gases
SO
2
ppm 10 (rel. humidity < 75%, non-condensing)
H
2
S
ppm 1.0 (rel. humidity < 75%, non-condensing)
Vibration resistance, operating conditions
According to IEC 60068-2-6
Mechanical shock resistance
According to IEC 60068-2-27
Repetitive shock resistance
According to IEC 60068-2-29
Drop and free fall
According to IEC 60068-2-31, free fall to IEC 60068-2-32
Protection type
IP20
Electromagnetic compatibility (EMC)
ESD
EN 61000-4-2
Electromagnetic fields
EN 61000-4-3
Burst
EN 61000-4-4
Surge
EN 61000-4-5
HF, asymmetric
EN 61000-4-6
Radiated interference (RFI)
EN 55016-2-3
Voltage fluctuations
EN 61131-2
Type test
To EN 61131-2
Approvals
CE, cUL (may be in preparation)
Gateways XN, basic modules
Gateways XNE, electronics modules XNE
Terminals
Dimensional data
To VDE 0611 Part 1/8.92 /
IEC/EN 60947-7-1
To VDE 0611 Part 1/8.92 /
IEC/EN 60947-7-1
Connection from above
Spring-loaded/screw terminals
Push-in spring-cage terminals
Cable stripped length
mm
8
8
Max. terminal capacity
mm
2
0.5 - 2.5
0.14 - 1.5
Connectable conductors
“
e” solid H07V-U
mm
2
0.5 - 2.5
0.25 - 1.5
“
f” flexible H 07V-K
mm
2
0.5 - 1.5
0.25 - 1.5
“
f” with ferrule without plastic collar to
DIN 46228-1 (ferrules gas-tight)
mm
2
0.5 - 1.5
0.25 - 1.5
“
f” with ferrule with plastic collar to
DIN 46228-1 (ferrules gas-tight)
mm
2
0.5 - 1.5
0.25 - 0.75
Gage pin IEC/EN 60947-1
A1
A1
