Automation products
Relay modules
2010 CA08103002Z-EN
Remote I/O XI/ON 14/121
Remote I/OXI/ONRelaymodules
XN-2DO-R-NC XN-2DO-R-NO XN-2DO-R-CO
Relay modules
Contact type 2 NC 2 N/O 2 change-over contacts
Rated voltage at supply terminal UL 24 V DC 24 V DC 24 V DC
Rated current drawn from supply
terminal
IL mA ≦ 20 ≦ 20 ≦ 20
Rated current drawn from module bus IMB mA ≦ 28 ≦ 28 ≦ 28
Insulation test Ui V AC 1500, 500 1500, 500 1500, 500
Heat dissipation W Normally 1 Normally 1 Normally 1
The following can be connected: Resistive loads
Inductive loads
Lamp loads
Resistive loads
Inductive loads
Lamp loads
Resistive loads
Inductive loads
Lamp loads
Nominal load voltage 230 V AC, 30 V DC 230 V AC, 30 V DC 230 V AC, 30 V DC
Output current for channel / 230 V AC
Maximum continuous current A 2 2 2
Maximum continuous
current, resistive load
5 A, load-dependent 5 A, load-dependent 5 A, load-dependent
Minimum load current mA 100 mA at 12 V DC 100 mA at 12 V DC 100 mA at 12 V DC
Output current for DC voltage
(resistive)
Load limit curve￫Page 14/109 Load limit curve￫Page 14/109 Load limit curve￫Page 14/109
Utilization factor g % 100 100 100
Lifespan at 230 V AC
At 5 A Opera-
tions
x 106 > 0.1 > 0.1 > 0.1
At 0.5 A Opera-
tions
x 106 > 1 > 1 > 1
Basic modules
Without C connection XN-S4...-SBBS XN-S4...-SBBS XN-S4...-SBBS
With C connection XN-S4...-SBCS XN-S4...-SBCS
