14/120

Automation products

Analog output modules

2010

CA08103002Z-EN

www.eaton.com

Remote I/O XI/ON

Remote I/OXI/ONAnalogoutputmodules

XN-1AO-I(0/4...20MA)

XN-2AO-I(0/4...20MA)

XN-2AO-U(-10/0...+10VDC) XNE-4AO-U/I

Analog output modules

Measured variables

Current

Current

Voltage

Voltage, current

Channels

Number 1

2

2

4

Rated voltage at supply terminal

U

L

24

V DC

24

V DC

24

V DC

24

V DC

Rated current drawn from supply

terminal

1)

I

L

mA

≦ 50

≦ 50

≦ 50

≦ 150

Rated current drawn frommodule bus

1)

I

MB

mA

≦ 39

≦ 40

≦ 43

≦ 40

Heat dissipation

W Normally 1

Normally 1

Normally 1

< 3

Output value, Voltage

Output voltage

V DC -

-

-10 - 10

V DC/ 0 - 10 V DC -10 - 10 V DC/ 0 - 10 V DC

Value representation

-

-

Standard, 16 bit/12 bit

left-aligned

Standard, 16-bit/12-bit

(

left-aligned)

Extended range, 16-bit/

12-

bit (left-aligned)

PA (NE43), 16-bit/12-bit

(

left-aligned)

The following can be connected:

-

-

2-

conductor + shield

2-

conductor

Load resistor

-

-

Resistive load

-

-

> 1000

> 1000

Capacitive load

μF

-

-

< 1

< 1

Transfer frequency

Hz

-

-

< 100

< 20

Recovery time

-

-

Resistive load

ms

-

-

< 0.1

< 1

Inductive load

ms

-

-

< 0.5

< 2

Capacitive load

ms

-

-

< 0.5

< 2

Short-circuit current

mA

-

-

≦ 40

≦ 40

Basic error limit at 23 °C

% -

-

< 0.2

< 0.2

Temperature coefficient

-

-

≦ 300 ppm/°C of full-scale

value

≦ 200 ppm/°C of full-

scale value

Output value, current

Output current

mA

0 - 20

mA/4 - 20 mA 0 - 20 mA/4 - 20 mA -

0 - 20

mA/4 - 20 mA

Value representation

Standard, 16 bit/12 bit

left-aligned

Standard, 16 bit/12 bit

left-aligned

-

Standard, 16-bit/12-bit

(

left-aligned)

Extended range, 16-bit/

12-

bit (left-aligned)

PA (NE43), 16-bit/12-bit

(

left-aligned)

The following can be connected:

2-

conductor + shield 2-conductor + shield -

2-

conductor

Load resistor

Resistive load

< 550

< 450

-

< 450

Inductive load

μH

< 1

< 1

-

< 1

Transfer frequency

Hz

< 200

< 200

-

< 20

Recovery time

Resistive load

ms

< 0.1

< 2

-

< 1

Inductive load

ms

< 0.5

< 2

-

< 2

Capacitive load

ms

< 0.5

-

-

< 2

Short-circuit current

mA

≦ 40

Basic error limit at 23 °C

%

< 0.2

< 0.2

-

< 0.2

Temperature coefficient

≦ 300 ppm/°C of

full-scale value

≦ 300 ppm/°C of

full-scale value

≦ 200 ppm/°C of

full-scale value

Basic modules

Without C connection

XN-S3...-SBB

XN-S3...-SBB

XN-S3...-SBB

Already built in

1)

Part of the XI/ON module’s electronics is supplied with module bus voltage (5 V DC), the other part through

the supply terminal (U

L

).
