5/38 Contactors
Auxiliary contact modules
2010 CA08103002Z-EN
Auxiliarycontactmodules
Terminal
type
Pole Conventional
thermal current
Ith = Ie
AC-1 at 60 °C
Contact
configuration
N/O = normally open
contact
SF= N/O early-make
NC = normally closed
contact
ÖS = NC late-break
Circuit
symbol
For use with Part no. Price
See price
list
Std. pack
Open
Ith = Ie
A
Auxiliary contact modules
With interlocked opposing contacts, except ...XHI(C)V
Top mounting auxiliary contacts
Screw
terminals
2 pole 16 1 N/O 1 NC DILM(C)7-10…
DILM(C)9-10…
DILM(C)12-10…
DILM(C)15-10…
DILM(C)17-10…
DILM(C)25-10…
DILM(C)32-10…
DILM38-…10
DILMP20…
DILMP32-10…
DILMP45-10…
DILL…
DILM32-XHI11
277376
5 off
– 2 NC DILM32-XHI02
277375
4 pole 2 N/O 2 NC DILM32-XHI22
277377
3 N/O 1 NC DILM32-XHI31
106112
Spring-
loaded
terminals
2 pole 16 1 N/O 1 NC DILM32-XHIC11
277751
– 2 NC DILM32-XHIC02
277750
4 pole 2 N/O 2 NC DILM32-XHIC22
277752
Screw
terminals
2 pole 16 2 N/O – DILM(C)7…
DILM(C)9…
DILM(C)12…
DILM(C)15…
DILM(C)17…
DILM(C)25…
DILM(C)32…
DILM38…
DILMP20…
DILMP32…
DILMP45…
DILL…
DILA-XHI20
276422
1 N/O 1 NC DILA-XHI11
276421
– 2 NC DILA-XHI02
276420
1 SF 1 ÖS DILA-XHIV11
276423
4 pole 16 4 N/O – DILA-XHI40
276428
3 N/O 1 NC DILA-XHI31
276427
2 N/O 2 NC DILA-XHI22
276426
1 N/O 3 NC DILA-XHI13
276425
– 4 NC DILA-XHI04
276424
1 N/O
1 SF
1 NC
1 ÖS
DILA-XHIV22
276429
Notes • Auxiliary NC usable as mirror contact according to IEC/EN 60947-4-1,
Annex F
• Interlocked opposing contacts according to IEC/EN 60947-5-1 Annex L,
inside the auxiliary contact modules, also for the
integrated auxiliary contacts of the DILM 7 - DILM32
Information relevant for export to North America
Product Standards IEC/EN 60947-4-1; UL 508;
CSA-C22.2 No. 14-05; CE marking
UL File No. E29184
UL CCN NKCR
CSA File No. 012528
CSA Class No. 3211-03
NA Certification UL Listed, CSA certified
21
22
33
34
21
22
31
32
21
22
31
32
43
44
53
54
21
22
33
34
53
54
43
44
21
22
33
34
21
22
31
32
21
22
31
32
43
44
53
54
54
63
64
53
54
53 61
62
51
52
61
62
58
57 65
66
54
63 73
64 74
53 83
84
54
53 61
62
73
74
83
84
54
53 61
62
71
72
83
84
53 61 71 81
82 72 62 54
51
52
61
62
71
72 82
81
58
57 65
66
71
72
83
84
