5/36 Leistungsschütze
Basic devices up to 200 A
2010 CA08103002Z-EN
Basicdevicesup to 200A
Rated operational current open Conventional thermal current
Ith = Ie AC-1 at 50 °C
Circuit symbol For use with
AC-1 Open
40 °C 55 °C 70 °C
Ith = Ie
A A A A
Contactors up to 200 A
4 pole
22 21 20 20 DILM32-XHI(C)…
DILA-XHI(V)(C)…
32 30 28 32 DILM32-XHI(C)…
DILA-XHI(V)(C)…
32 30 28 32
45 41 39 45
45 41 39 45
63 60 54 63 DILM150-XHI(A)(V)…
or
DILM1000-XHI11-SA 1)
or
DILM1000-XHI(V)11-SI1)
80 76 69 80
125 116 108 125 DILM150-XHI(A)(V)…
DILM1000-XHI(V)… 1)
160 150 138 160
200 188 172 200
Notes 1) DILM1000-XHI…can only be fitted on the left of DILMP.
Contacts to EN 50012.
For DC operated contactors DILMP20 the following applies:
• Integrated varistor suppressor circuit.
For DC operated contactors DILMP32 - DILMP200 the following applies:
• Integrated suppressor circuit in actuating electronics.
For AC operated contactors DILMP125 - DILMP200 the following applies:
• Integrated suppressor circuit in actuating electronics.
For DILMP32-01 and DILMP45-01 the following applies:
• With mirror contact.
2
3 5
4 6
A1
A2
1 7
8
21
22
A1
A2
1
2
3
4
5
6
7
8
2
3 5
4 6
A1
A2
1 7
8
2
3 5
4 6
A1
A2
1 7
8
DILMP 4 pole HPL05036EN
