Eaton Industrial Switchgear - xStart switching, protections and actuating motors

37 / 439

2010 CA08103002Z-EN
Contactors DILM, DILH
Comfort devices greater than 150 A
Part no. Price
See price
list
Std. pack Notes
DILM185A/22(RAC240)1)
139537
1 off
DILM225A/22(RAC240)1)
139547
DILM250/22(RA250)2)
208201
DILM300A/22(RA250)1) 2)
139556
DILM400/22(RA250)3)
208209
DILM500/22(RA250)3)
208213
DILM580/22(RA250)3)
208216
DILM650/22(RA250)3)
208219
DILM750/22(RA250)3)
208222
DILM820/22(RA250)3)
208225
DILM1000/22(RA250)3)
267214
DILM1600/22(RAW250) 3)
106727
Information relevant for export to North America
1)
NA Certification Request filed for UL and CSA
2)
Product Standards IEC/EN 60947-4-1; UL 508; CSA-C22.2 No. 14-05; CE marking
UL File No. E29096
UL CCN NLDX
CSA File No. 1017510
CSA Class No. 3211-04
NA Certification UL Listed, CSA certified
3)
Product Standards IEC/EN 60947-4-1; UL 508; CSA-C22.2 No. 14-05; CE marking
UL File No. E29096
UL CCN NLDX
CSA File No. 012528
CSA Class No. 3211-04
NA Certification UL Listed, CSA certified
See also Additional approvals ￫Page 5/86
Conventional DILM 185 A, DILM 225 A DILM250 to DILM1000, DILH1400 DILM1600 to DILH 2600
A1/A2 are attached
to power supply as
normal
Directly from the PLC
A 24 V output from
the PLC can be
directly connected
to the terminals A4/
A24.
From a low-power command device
Low-power
actuating devices
such as PCB relays,
pilot devices or
position switches
can be directly
connected to A10/
A11.
① Stopping in the event of an emergency (emergency switching off)
② Max. cable capacitance 6 nF
A2
A1
(+) L1
(–) N
a
A10
A11
A2
A1
A3
A4
(+) L1
(–) N
a
A10
A11
A2
A1
A3
A4
TY
TX
( +) L1
(–) N
a
A10
A11
A2
A1
A3
A4
24 V
GND
(+) L1
(–) N
a A2
A1
A3
A4
24 V
GND
( +) L1
(–) N
a
A10
A11
TY
TX
A10
A11
A2
A1
A3
A4
b
a
(+) L1
(–) N
A10
A11
A2
A1
A3
A4
b
a
( +) L1
(–) N
TY
TX
5/33
DILM...-S/22... HPL05033EN
