5/30 Contactors DILM, DILH
Standard devices greater than 150 A
2010 CA08103002Z-EN
Rated
operational
current
Max. motor rating for
three-phase motors 50 - 60 Hz
Conventional
thermal current
Ith = Ie
AC-1 at 40 °C
Circuit symbol For use with
AC-3 AC-3 AC-4 Open
380 V
400 V 220 V
230 V
380 V
400 V 660 V
690 V
220 V
230 V
380 V
400 V 660 V
690 V
Ith = Ie
Ie P P P P P P A
A kW kW kW kW kW kW
Standard device for currents greater than 150 A
DILM complete device
250 75 132 240 62 110 189 400 DILM820-XHI…
300 90 160 195 75 132 160 430 DILM820-XHI…
400 125 200 344 92 160 283 612 DILM820-XHI…
500 155 250 344 112 200 344 857 DILM820-XHI…
580 185 315 344 112 200 344 920 DILM820-XHI…
Notes 1) Availability from August 2010.
Previous DILM300/22, see Online Catalog at
For all contactors the following applies:
• 660 V, 690 V or 1000 V: do not reverse directly
• Integrated suppressor circuit in actuating electronics.
2
3 5 13 21 31
4 6 14 22 32
43
44
A1
A2
1
2
3 5 13 21 31
4 6 14 22 32
43
44
A1
A2
1
2
3 5 13 21 31
4 6 14 22 32
43
44
A1
A2
1
2
3 5 13 21 31
4 6 14 22 32
43
44
A1
A2
1
2
3 5 13 21 31
4 6 14 22 32
43
44
A1
A2
1
DILM…-S contactors are actuated conventionally
① Stopping in the event of an emergency (emergency switching off)
A2
A1
(+) L1
(–) N
a
Accessories Page
Auxiliary contact modules ￫5/40
Enclosures
Further actuating voltages ￫5/81
DILM...S/22... HPL05030EN
