Contactors DILM, DILH
Comfort devices greater than 150 A
Notes
Information relevant for export to North America
1)
Product Standards IEC/EN 60947-4-1; UL 508; CSA-C22.2 No. 14-05; CE marking
UL File No. E29096
UL CCN NLDX
CSA File No. 012528
CSA Class No. 3211-04
NA Certification UL Listed, CSA certified
2)
NA Certification Request filed for UL and CSA
Conventional DILH1400 DILM1600 to DILH 2600
A1/A2 are attached to power
supply as normal
Directly from the PLC
A 24 V output from the PLC can
be directly connected to the
terminals A4/A24.
From a low-power command device
Low-power actuating devices
such as PCB relays, pilot
devices or position switches
can be directly connected to
A10/A11.
① Stopping in case of emergency (Emergency-stop)
② Max. cable capacitance 6 nF
A10
A11
A2
A1
A3
A4
( +) L1
(–) N
a
A10
A11
A2
A1
A3
A4
TY
TX
( +) L1
(–) N
a
A10
A11
A2
A1
A3
A4
24 V
GND
(+) L1
(–) N
a A2
A1
A3
A4
24 V
GND
( +) L1
(–) N
a
A10
A11
TY
TX
A10
A11
A2
A1
A3
A4
b
a
(+) L1
(–) N
A10
A11
A2
A1
A3
A4
b
a
(+) L1
(–) N
TY
TX
