5/40 Contactors
Auxiliary contact module
2010 CA08103002Z-EN
Auxiliarycontactmodule
Connection
type
Pole conventional
thermal
current
Ith = Ie
AC-1 at 60 °C
Contact
configuration
N/O = normally
open contact
SF = N/O early
make
NC = normally
closed contact
ÖS = NC late-
break
Circuit
symbol
For use with Part no.
Article no.
Price
See
price
list
Std. pack Notes
Open
Ith = Ie
A
Auxiliary contact modules
With interlocked opposing contacts
Top mounting auxiliary contacts
Screw
terminals
2 pole 16 2 N/O – DILM40…
DILM50…
DILM65…
DILM72…
DILM80…
DILM95…
DILM115…
DILM150…
DILM170…
DILMP63…
DILMP80…
DILMP125…
DILMP160…
DILMP200…
DILM150-XHI20
277945
5 off Interlocked
opposing contacts
according to
IEC/EN 60947-5-1
Annex L, inside the
auxiliary contact
modules
Auxiliary NC
usable as mirror
contact according
toIEC/EN60947-4-1,
Annex F
1 N/O 1 NC DILM150-XHI11
277946
1 N/O 1 NC DILM150-XHIA11
283463
– 2 NC DILM150-XHI02
277947
Screw
terminals
4 pole 16 4 N/O – DILM150-XHI40
277948
3 N/O 1 NC DILM150-XHI31
277949
2 N/O 2 NC DILM150-XHI22
277950
2 N/O 2 NC DILM150-XHIA22
283464
1 N/O 3 NC DILM150-XHI13
277951
– 4 NC DILM150-XHI04
277952
1 N/O
1 SF
1 NC
1 ÖS
DILM150-XHIV22
277953
–
High version1)
Screw
terminals
2 pole 16 2 N/O – DILM7…
DILM9…
DILM12…
DILM15…
DILL…
DILA-XHIT20
101042
5 off Interlocked
opposing contacts
according to
IEC/EN 60947-5-1
Annex L, inside the
auxiliary contact
modules
Auxiliary NC
usable as mirror
contact according
toIEC/EN60947-4-1,
Annex F
1 N/O 1 NC DILA-XHIT11
101043
– 2 NC DILA-XHIT02
101041
4 pole 2 N/O 2 NC DILA-XHIT22
101044
Notes 1) Suitable for the combination with electrical wiringlinks
in tool-less plug connection usable with:
DILM12-XSL
DILM12-XRL
DILM12-XS1
PKZM0-XDM12
PKZM0-XRM12
PKZM0-XSM12
1 PKZM0
2 DILM7 - DILM15
3 DILA-XHIT
4 PKZM0-XDM12
Information relevant for export to North
America
Product Standards IEC/EN 60947-4-1;
UL 508; CSA-C22.2
No. 14-05; CE mark-
ing
UL File No. E29184
UL CCN NKCR
CSA File No. 012528
CSA Class No. 3211-03
NA Certification UL Listed,
CSA certified
