5/44 Contactors
Contactors for power factor correction
2010 CA08103002Z-EN
Engineering
Ordering data Switching power
230 V 400 V
420 V
440 V
525 V 690 V
Part no. Page kvar kvar kvar kvar
Individual compensation, open version
DILM7-…(…) ￫ 5/18 1.5 3 3.5 5
DILM9-…(…) ￫ 5/18 2 4 4.5 6
DILM12-…(…) ￫ 5/18 2.5 4.5 5.5 7
DILM15-…(…) ￫ 5/18 2.5 4.5 5.5 7
DILM17-…(…) ￫ 5/18 6.5 12 14.5 19
DILM25-…(…) ￫ 5/18 7 13.5 16 21
DILM32-…(…) ￫ 5/18 7.5 14.5 17 22.5
DILM40(…) ￫ 5/20 11 20.5 24.5 32
DILM50(…) ￫ 5/20 11.5 22 26 34.5
DILM65(…) ￫ 5/20 12.5 23.5 28 37
DILM80(…) ￫ 5/20 16 30.5 36.5 48
DILM95(…) ￫ 5/20 18 34 41 54
DILM115(…) ￫ 5/20 24 46 54.5 72
DILM150(…) ￫ 5/20 28 53 63.5 83.5
DILM185A(…) ￫ 5/32 87 150 190 150
DILM300A(…) ￫ 5/32 115 200 265 200
DILM580(…) ￫ 5/32 175 300 400 300
Group compensation, with choke, open version
DILM7-…(…) ￫ 5/18 4 7 7.5 12
DILM9-…(…) ￫ 5/18 5 8 10 14
DILM12-…(…) ￫ 5/18 5.5 10 12 16
DILM15-…(…) ￫ 5/18 5.5 10 12 16
DILM17-…(…) ￫ 5/18 7.5 18 20 28
DILM25-…(…) ￫ 5/18 10 20 23 30
DILM32-…(…) ￫ 5/18 12.5 25 25 32
DILM40(…) ￫ 5/20 15 30 30 40
DILM50(…) ￫ 5/20 20 40 40 48
DILM65(…) ￫ 5/20 25 50 50 57
DILM80(…) ￫ 5/20 30 60 70 90
DILM95(…) ￫ 5/20 35 70 80 104
DILM115(…) ￫ 5/20 50 95 100 125
DILM150(…) ￫ 5/20 55 115 115 152
DILM185A(…) ￫ 5/32 80 150 200 260
DILM225A(…) ￫ 5/32 100 175 230 300
DILM250(…) ￫ 5/32 110 190 260 340
DILM300A(…) ￫ 5/32 130 225 290 390
DILM400(…) ￫ 5/32 160 280 370 480
DILM500(…) ￫ 5/32 220 390 500 680
Group compensation, without choke, open version
DILK12-…(…) ￫ 5/43 7.5 12.5 16.7 20
DILK20-…(…) ￫ 5/43 11 20 25 33.3
DILK25-…(…) ￫ 5/43 15 25 33.3 40
DILK33-…(…) ￫ 5/43 20 33.3 40 55
DILK50-…(…) ￫ 5/43 25 50 65 85
DILM185A(…) ￫ 5/32 66 115 145 115
DILM300A(…) ￫ 5/32 85 150 195 150
DILM580(…) ￫ 5/32 145 250 333 250
Notes Use of the contactors DILM without series resistor for group compensation
When using the contactors for group compensation in a system without chokes each capacitor must have a minimum
induction of approx. 6 μH to limit the peak inrush current. This corresponds to an air-cored coil with 5 windings and a coil
diameter of approximately ⌀ 140 mm. The conductor cross section must correspond to the rated operational current.
DILM, DILK
