Contactors

Complete device up to 170 A

AC operation

DC operation

Part no.

Article no.

Price

See

price list

Part no.

Article no.

Price

See

price list

Std. pack

Notes

DILM7-21(230V50HZ)

276620

DILM7-21(24VDC)

276635

off

DILM7-22(230V50HZ)

106360

DILM7-22(24VDC)

106367

DILM7-32(230V50HZ)

276655

DILM7-32(24VDC)

276670

DILM9-21(230V50HZ)

276760

DILM9-21(24VDC)

276775

DILM9-22(230V50HZ)

106361

DILM9-22(24VDC)

106368

DILM9-32(230V50HZ)

276795

DILM9-32(24VDC)

276810

DILM12-21(230V50HZ)

276900

DILM12-21(24VDC)

276915

DILM12-22(230V50HZ)

106362

DILM12-22(24VDC)

106369

DILM12-32(230V50HZ)

276935

DILM12-32(24VDC)

276950

DILM15-22(230V50HZ)

106363

DILM15-22(24VDC)

106370

For all DC operated contactors DILM7 - DILM15 the following applies:

•

Integrated varistor suppressor circuit.

For DC operated contactors DILM17 - DILM170 the following applies:

•

Integrated suppressor circuit in actuating electronics

For AC operated contactors DILM115 - DILM170 the following applies:

•

Integrated suppressor circuit in actuating electronics

For DILM7 - DILM150 the following applies:

•

With mirror contact.

Contacts to EN 50012

DILM17-21(230V50HZ)

277068

DILM17-21(RDC24)

277082

DILM17-22(230V50HZ)

106364

DILM17-22(RDC24)

106371

DILM17-32(230V50HZ)

277100

DILM17-32(RDC24)

277114

DILM25-21(230V50HZ)

277196

DILM25-21(RDC24)

277210

DILM25-22(230V50HZ)

106365

DILM25-22(RDC24)

106372

DILM25-32(230V50HZ)

277228

DILM25-32(RDC24)

277242

DILM32-21(230V50HZ)

277324

DILM32-21(RDC24)

277338

DILM32-22(230V50HZ)

106366

DILM32-22(RDC24)

106373

DILM32-32(230V50HZ)

277356

DILM32-32(RDC24)

277370

Accessories

Page

Overload relay

￫Chapter 6

Suppressor

￫5/54

Accessories

￫5/56
