Motor-protective circuit-breakers PKZ2
Actuating voltages
2010 CA08103002Z-EN
7/71
Undervoltage release
When ordered separately
AC U-PKZ2(...) U-HI20-PKZ2(...) UVHI-PKZ2(...)
Article no.1) Article no.1) Article no.1)
Standard voltage See price list See price list See price list
24 V 50 Hz 055085 - –
110 V 50 Hz,
120 V 60 Hz
– 063655 –
220 V 50 Hz,
240 V 60 Hz
065685 063656 –
230 V 50 Hz,
240 V 60 Hz
065766 065768 065770
400 V 50 Hz,
440 V 60 Hz
065767 – –
24 V 50/60 Hz – 063659 –
Non-standard voltages with the exception of the shown
standard voltages2).
– See price list –
...V 50Hz (24 – 600 V) – 9075373) –
...V 60Hz (24 – 600 V) – 9075383) –
DC
Standard voltage See price list – –
24V DC 014463 – –
48V DC 028701 – –
Notes 1) To obtain the complete part number, append the actuating voltage (...) to the part nos. given above.
Devices with dual-voltage coils must be ordered with a single article no.
2) For non-standard voltages, specify the required actuating voltage within the indicated range (... - ... V).
3) Minimum order quantity: 10 units.
(High-capacity) contact modules
AC S-PKZ2(...) S/HI20-S-PKZ2(...) SE1A/11-PKZ2(...) SE1A/20-PKZ2(...)
Article no.1) Article no.1) Article no.1) Article no.1)
Standard voltage See price list See price list See price list See price list
24 V 50 Hz 026609 – – –
48 V 50 Hz 062651 056383 – –
240 V 50 Hz 001882 057048 058716 058717
24 V 60 Hz 062501 – – –
110 V 50 Hz,
120 V 60 Hz
063694 063701 063709 063716
190 V 50 Hz,
220 V 60 Hz
063695 – 063710 063717
220 V 50 Hz,
240 V 60 Hz
063699 063706 – –
230 V 50 Hz,
240 V 60 Hz
063696 063703 063711 063718
400 V 50 Hz,
440 V 60 Hz
063697 – 063712 063719
24 V 50/60 Hz 062500 – 058720 058721
110 V 50/60 Hz – – 058696 –
230 V 50/60 Hz 065103 056395 058712 058713
DC S-G-PKZ2(...) SE1A-G-10-PKZ2(...)
Article no.1) Article no.1)
Standard voltage See price list See price list
24 V DC 070921 058856
Notes 1) To obtain the complete part number, append the actuating voltage (...) to the part nos. given above.
Devices with dual-voltage coils must be ordered with a single article no.
