Motor-protective circuit-breakers PKZ2
Busbar adapters
2010
CA08103002Z-EN
www.eaton.comBusbaradapters
Rated
operating
voltage
Cable
cross-
section
Adapter
width
Mounting
rails
For use with
Part no.
Article no.
Price
See price
list
Std. pack
Notes
U
e
V
mm Number
Busbar adapters for PKZ
Approved to UL 508.
For fitting to flat copper busbar with 60 mm between busbar centers, suitable for 5 mm and
10
mm busbar thickness.
Rated operational current 63 A
For motor-protective circuit breakers.
690
AWG 8
(10
mm²)
72
1
PKZ2
BBA2-63
1)
101458
4
Off
–
690
AWG 8
(10
mm²)
54
1
PKZM4
BBA4-63
1)
101457
4
Off
–
For DOL starters.
690
AWG 8
(10
mm²)
72
2
PKZ2 + DILM7
PKZ2 + DILM9
PKZ2 + DILM12
PKZ2 + DILM15
PKZ2 + DILM17
PKZ2 + DILM25
PKZ2 + DILM32
PKZ2 + DILM40
BBA2L-63
1)
101480
2
Off
–
690
AWG 8
(10
mm²)
55
2
PKZM4 + DILM17
PKZM4 + DILM25
PKZM4 + DILM32
PKZM4 + DILM40
PKZM4 + DILM50
PKZM4 + DILM65
BBA4L-63
1)
101459
4
Off
The following can be used
for an electrical
connection:
PKZM4 + DILM40 bis
DILM65: PKZM4-XM65DE
usable.
690
AWG 8
(10
mm²)
72
2
PKZ2 + DILM7
PKZ2 + DILM9
PKZ2 + DILM12
PKZ2 + DILM15
PKZ2 + DILM17
PKZ2 + DILM25
PKZ2 + DILM32
PKZ2 + DILM38
PKZ2 + DILM40
PKZ2 + DILM50
PKZ2 + DILM65
SE1A/…-PKZ2 +
C-PKZ2
S-PKZ2 + C-PKZ2
BBA2-63/2TS
2)
116900
4
Off
For DOL starters.
Rated operational current 80 A
Can be used universally.
690
–
72
2
PKZ2 + DILM7
PKZ2 + DILM9
PKZ2 + DILM12
PKZ2 + DILM15
PKZ2 + DILM17
PKZ2 + DILM25
PKZ2 + DILM32
PKZ2 + DILM38
PKZ2 + DILM40
PKZ2 + DILM50
PKZ2 + DILM65
BBA2-80/2TS-S
2)
116901
4
Off
Universal adapter for 1,
2
and 3-phase
applications, not suitable
without additional UL/CSA
component.
For conductor cross-
section, round conductors
up to 16 mm
2
or AWG6.
Notes
Information relevant for export to North America
1)
Product Standards UL 508A; CSA-C22.2 No. 14; IEC60439-1;
CE marking
UL File No.
E300273
UL CCN
NMTR
CSA File No.
232140
CSA Class No.
3211-37
NA Certification
UL Recognized, CSA certified
Max. Voltage Rating 600 V AC
2)
Product Standards UL 508A; CSA-C22.2 No. 14; IEC60439-1; CE marking
UL File No.
E300273
UL CCN
NMTR
NA Certification
UL Recognized, CSA certified
Max. Voltage Rating 600 V AC
