7/70 Motor-protective circuit-breakers PKZ2
Actuating voltages
2010 CA08103002Z-EN
Compact starters
Contact module with 1 normally open and 1 normally closed auxiliary contact
AC PKZ2/ZM-1/SE1A/
11(...)
PKZ2/ZM-1.6/SE1A/
11(...)
PKZ2/ZM-2.4/SE1A/
11(...)
PKZ2/ZM-4/SE1A/
11(...)
PKZ2/ZM-6/SE1A/
11(...)
Article no. 1) Article no. 1) Article no.1) Article no.1) Article no. 1)
Standard voltage See price list See price list See price list See price list See price list
230 V 50 Hz,
240 V 60 Hz 063364 063372 063382 063392 063402
110 V 50/60 Hz – – – – 063408
230 V 50/60 Hz 063369 063379 063389 063399 063409
Compact starters
Contact module with 1 normally open and 1 normally closed auxiliary contact
AC PKZ2/ZM-10/
SE1A/11(...)
PKZ2/ZM-16/
SE1A/11(...)
PKZ2/ZM-25/
SE1A/11(...)
PKZ2/ZM-32/
SE1A/11(...)
PKZ2/ZM-40/
SE1A/11(...)
PKZ2/
SE1A/11(...)
Article no. 1) Article no. 1) Article no. 1) Article no. 1) Article no.1) Article no.1)
Standard voltage See price list See price list See price list See price list See price list See price list
230 V 50 Hz,
240 V 60 Hz 063412 063422 063432 063442 063452 082142
110 V 50/60 Hz 063418 063428 063438 063448 063458 –
230 V 50/60 Hz 063419 063429 063439 063449 063459 082148
High-capacity compact starters
Contact module with 1 normally open and 1 normally closed auxiliary contact
AC PKZ2/ZM-1/S(...) PKZ2/ZM-1.6/S(...) PKZ2/ZM-2.4/S(...) PKZ2/ZM-4/S(...) PKZ2/ZM-6/S(...)
Article no. 1) Article no. 1) Article no.1) Article no.1) Article no. 1)
Standard voltage See price list See price list See price list See price list See price list
230 V 50 Hz,
240 V 60 Hz 063472 063482 063492 063502 063512
110 V 50/60 Hz 063478 063488 063498 063508 063518
230 V 50/60 Hz 063479 063489 063499 063509 063519
High-capacity compact starters
Contact module with 1 normally open and 1 normally closed auxiliary contact
AC PKZ2/ZM-10/
S(...)
PKZ2/ZM-16/
S(...)
PKZ2/ZM-25/
S(...)
PKZ2/ZM-32/
S(...)
PKZ2/ZM-40/
S(...)
PKZ2/S(...)
Article no. 1) Article no. 1) Article no. 1) Article no. 1) Article no.1) Article no.1)
Standard voltage See price list See price list See price list See price list See price list See price list
110 V 50 Hz,
120 V 60 Hz – – – – – 063570
230 V 50 Hz,
240 V 60 Hz 063522 063532 063542 063552 063562 063572
24 V 50/60 Hz – – – – – 063577
110 V 50/60 Hz 063528 063538 063548 063558 063568 –
230 V 50/60 Hz 063529 063539 063549 063559 063569 063579
Notes 1) To obtain the complete part number, append the actuating voltage (...) to the part nos. given above.
Devices with dual-voltage coils must be ordered with a single article no.
