Motor-protective circuit-breakers PKZ2
Motor-protective circuit-breakers, circuit-breaker
2010 CA08103002Z-EN
7/75
Approvals for world markets
Approved rating data 1)
UL 508/CSA C 22.2 No. 14
Maximum motor rating Setting ranges Maximum protective device to UL/CSA
Three-phase current Overload
releases
Short-circuit-
releases
Group protection1)
Up to max.
short-circuit
rating
Maximum
fuse rating
Maximum
circuit
breaker
200 V 230 V 460 V 575 V 480 V 600 V
HP HP HP HP A A kA kA A A
Motor-protective circuit-
breakers PKZ2 “Manual Motor Starter with thermal and magnetic trip”
PKZ2/ZM-0.6 2) 0.4 – 0.6 5 – 8 65 42 500 600
PKZ2/ZM-1 ½ ½ 0.6 – 1 8 – 14 65 42 500 600
PKZ2/ZM-1.6 ¾ 1 1 – 1.6 14 – 22 65 42 500 600
PKZ2/ZM-2.4 ½ ½ 1 1½ 1.6 – 2.4 20 – 35 65 42 500 600
PKZ2/ZM-4 1 1 2 3 2.4 – 4 35 – 55 65 42 500 600
PKZ2/ZM-6 1½ 1½ 3 5 4 – 6 50 – 80 65 42 500 600
PKZ2/ZM-10 2 3 5 7½ 6 – 10 80 – 140 65 42 500 600
PKZ2/ZM-16 3 5 10 10 10 – 16 130 – 220 65 42 500 600
PKZ2/ZM-25 7½ 7½ 20 25 16 – 27 200 – 350 65 42 500 600
PKZ2/ZM-32 10 10 20 30 24 – 32 275 – 425 65 42 500 600
PKZ2/ZM-40 10 15 30 30 32 – 42 350 – 500 65 42 500 600
High-power compact starters
PKZ2 “Manual Motor Starter with thermal, magnetic trip and contactor”
PKZ2/ZM-0.6/S(...) 2) 0.4 – 0.6 5 – 8 65 42 2000 2000
PKZ2/ZM-1/S(...) ½ ½ 0.6 – 1 8 – 14 65 42 2000 2000
PKZ2/ZM-1.6/S(...) ¾ 1 1 – 1.6 14 – 22 65 42 2000 2000
PKZ2/ZM-2.4/S(...) ½ ½ 1 1½ 1.6 – 2.4 20 – 35 65 42 2000 2000
PKZ2/ZM-4/S(...) 1 1 2 3 2.4 – 4 35 – 55 65 42 2000 2000
PKZ2/ZM-6/S(...) 1½ 1½ 3 5 4 – 6 50 – 80 65 42 2000 2000
PKZ2/ZM-10/S(...) 2 3 5 7½ 6 – 10 80 – 140 65 42 2000 2000
PKZ2/ZM-16/S(...) 3 5 10 10 10 – 16 130 – 220 65 42 2000 2000
PKZ2/ZM-25/S(...) 7½ 7½ 20 25 16 – 27 200 – 350 65 42 2000 2000
PKZ2/ZM-32/S(...) 10 10 20 30 24 – 32 275 – 425 65 42 2000 2000
PKZ2/ZM-40/S(...) 10 15 30 30 32 – 42 350 – 500 65 42 2000 2000
High-capacity contact modules " Contact module" in combination with PKZ2/ZM(R)-... motor-protective circuit-breakeror base for separate mounting of
EZ-PKZ2
S-PKZ2(...) 10 15 30 30
S/HI20-S-PKZ2(...) 10 15 30 30
S-G-PKZ2(...) 10 15 30 30
Reversing combination " Reversing combination" in combination with trip block ZM-...PKZ2 for motor protection
PKZ2/SW-MV-11(...) 10 15 30 30
Reversing busbar sys- 42 A 600 V AC
A BK50/3-PKZ2 terminal must be ordered separately for UL/CSA use.
1) Caution: Changed requirements for
group protection
2) Calculate motor power in this range according to the rated operational current.
