Motor-protective circuit-breakers PKZ2
Remote operators
2010
CA08103002Z-EN
www.eaton.com7/81
Remoteoperators
A-PKZ2…
Shunt release (for power circuit-breakers)
Rated impulse withstand voltage
U
imp
V AC 6000
Overvoltage category/pollution degree
III/3
Terminal capacity
Solid or flexible conductor with ferrule
mm
2
1
x (0.75 - 2.5)
2
x (0.75 - 2.5)
Solid or stranded
AWG 22 - 14
Rated operating voltage
U
e
V AC 24 - 600
Rated operating voltage
U
e
V DC 24 - 250
Operating range
AC voltage
x U
s
0.7 - 1.1
DC voltage
x U
s
0.7 - 1.1
Power consumption
AC voltage
AC pick-up rating
Pick-up
VA
5
AC consumption when closed
Holding
VA
3
DC voltage
DC pick-up rating
Pick-up
W 3
DC consumption when closed
Holding
W 0.3
RE-PKZ2
RS-PKZ2
Remote drives
Rated impulse withstand voltage
U
imp
V AC 6000
6000
Overvoltage category/pollution degree
III/3
III/3
Rated operating voltage
U
e
V AC 380 - 440
380 - 440
Rated operating voltage
U
e
V AC/DC 24 - 240
24 - 240
Safe isolation to VDE 0106 Part 101 and Part 101 A1 between the auxiliary
contacts and main circuits
V AC 500
500
Required short-time rating (30 ms)
VA/W 700
700
Control transformer short-time rating
VA
1000
1000
Short-circuit voltage
% 4.4
4.4
Closing delay
ms
≦ 30
≦ 30
Opening delay
ms
≦ 30
≦ 30
Reset time to OFF
ms
≦ 30
≦ 30
Maximum operating frequency
Max. operating frequency
Ops/h 60
60
Operating range
AC voltage
x U
s
0.85 - 1.1
0.85 - 1.1
DC voltage
x U
s
0.85 - 1
0.85 - 1
Lifespan, electrical
Operations x 10
6
0.05
0.05
Integrated auxiliary contact (signal manual/automatic 33/34)
Thermal rated operational current
I
th
A
1.5
1.5
Rated operational current
AC-14
230/240
V
I
e
A
1.5
1.5
400/415
V
I
e
A
1
1
440
V
I
e
A
0.5
0.5
Terminal capacity
Solid or flexible conductor with ferrule
mm
2
1
x (0.75 - 2.5)
2
x (0.75 - 2.5)
1
x (0.75 - 2.5)
2
x (0.75 - 2.5)
Solid or stranded
AWG 22 - 14
22 - 14
BK…-PKZ2, B3.1/…-PKZ2
Supply terminal and three-phase commoning link
Rated impulse withstand voltage
U
imp
V AC 6000
Overvoltage category/pollution degree
III/3
Rated operating voltage
U
e
V AC 690
Rated uninterrupted current
I
u
A
120
RE-PKZ, RS-PKZ
