Motor-protective circuit-breakers PKZ2
Accessories
2010 CA08103002Z-EN
7/77
Accessories
Approved rating data 1) For use with Pilot Duty General Use
Ordering data, motor-protective circuit-breaker PKZ2/S-SP
”Self-Protected Starter” ￫Page 7/53
AC DC
Accessories
Standard auxiliary contacts NHI11-PKZ2 PKZ2/ZM..., PKZ2...SP A 600, R 300 5 A – 600 V 0.5 A – 250 V
NHI22-PKZ2 PKZ2/ZM..., PKZ2...SP 10 A – 300 V
NHI11S-PKZ2 PKZ2/ZM-...
NHI22S-PKZ2 PKZ2/ZM-...
NHI2-11S-PKZ2 PKZ2/ZM-...
Trip-indicating auxiliary contacts AGM2-11-PKZ2 PKZ2/ZM..., PKZ2...SP A 600, R 300 10 A – 600 V 0.5 A – 250 V2)
Short-circuit indicators K-AGM-PKZ2 PKZ2/ZM..., PKZ2...SP
Shunt release A-PKZ2-... PKZ2/ZM..., PKZ2...SP 24 – 600 V 24 – 250 V
U-PKZ2(...) PKZ2/ZM..., PKZ2...SP 24 – 600 V 24 – 125 V
U-HI20-PKZ2(...) PKZ2/ZM..., PKZ2...SP 24 – 600 V 24 – 125 V
B 600, R 300 10 A – 600 V 0.5 A – 250 V
UVHI-PKZ2(...) PKZ2/ZM..., PKZ2...SP 24 – 600 V 24 – 125 V
B 600, R 300 10 A – 600 V 0.5 A – 250 V
Auxiliary contacts for contact
module
HI11-S-PKZ2 PKZ2/ZM-... A 600, R 300 10 A – 600 V 0.5 A – 250 V2)
HI20-S-PKZ2 PKZ2/ZM-... A 600 10 A – 600 V
HI11-S/EZ-PKZ2 PKZ2/ZM-... A 600, R 300 5 A – 600 V 0.5 A – 250 V2)
10 A – 300 V
Remote operator RE-PKZ2 PKZ2/ZM..., PKZ2...SP 3)
RS-PKZ2 PKZ2/ZM..., PKZ2...SP D 300 – R 300 1.5 A – 240 V AC
0.6 A – 600 V AC
Amplifier module for
remote drives
ETS4-VS3 PKZ2/ZM..., PKZ2...SP B 300 – R 300 5 A – 250 V AC
Clip plates C-PKZ2 PKZ2/ZM-...
Door coupling handles H-PKZ2 PKZ2/ZM..., PKZ2...SP
RH-PKZ2 PKZ2/ZM..., PKZ2...SP
Extension shaft A-H-PKZ2 PKZ2/ZM..., PKZ2...SP
Base for separate mounting EZ-PKZ2 –
Three-phase commoning links B3.1/3-PKZ2 PKZ2/ZM..., PKZ2...SP max. 100 A
B3.1/2-PKZ2 PKZ2/ZM..., PKZ2...SP max. 85 A
Connecting Terminals for
three-phase commoning links
BK50/3-PKZ2 PKZ2/ZM..., PKZ2...SP max. 100 A
Terminal capacity AWG 14-0
Torque 4.5 Nm
Padlocking feature SVB-PKZ2 PKZ2/ZM..., PKZ2...SP
Mechanical interlock MV-PKZ2 –
Coding pins CS-PKZ2 PKZ2/ZM..., PKZ2...SP
Busbar adapters AD-... PKZ2/ZM..., PKZ2...SP
Notes Terminal capacities for all PKZ2 system add-on modules:
• Cables min. AWG 18, max. AWG 14
• Torque 1.0 Nm
1) Device for world markets IEC = UL/CSA.
2) >150 V same polarity.
3) Maximum actuating voltage 120 V 60 Hz or 120 V DC.
