DC string circuit-breakers, DC switch-disconnectors
2010 CA08103002Z-EN
7/87
Engineering
P-SOL and PKZ-SOL wiring
Switch-disconnector P-SOL String circuit-breaker PKZ-SOL
Non-earthed grid Earthed grid Non-earthed grid Earthed grid
SOL internal circuit
SOL20/2MC3
SOL20/2MC4
SOL30/2MC3
SOL30/2MC4
SOL20/2MV
SOL30/2MV
SOL20/4MC3
SOL20/4MC4
SOL30/4MC3
SOL30/4MC4
SOL60/4MC3
SOL60/4MC4
SOL60/4MV SOL60/8MC3
SOL60/8MC4
1000 VDC
1 3 5
2 4 6
1000 VDC
1 3 5
2 4 6
900 VDC
1 3 5
2 4 6
900 VDC
1 3 5
2 4 6
- Strings + Strings
Output
Input
+ -
1 3 5
2 4 6
- Strings + Strings
Output (M16)
Input (M12)
+ -
1 3 5
2 4 6
- Strings + Strings
Output
Input
+ -
1 3 5
2 4 6
- Strings + Strings
Output (M20)
Input
+ -
1
+ -
3 5
2 4 6
- Strings + Strings
Input (M12)
Output (M20)
+ -
+ -
1 3 5
2 4 6
- Strings + Strings
Input
Output (M20)
+ -
+ -
1 3 5
2 4 6
P-SOL, PKZ-SOL, SOL
