SWD input/outputmodules
EU5E-SWD-8DX EU5E-SWD-4D4D EU5E-SWD-4D2R
General
Standards IEC/EN 61131-2
EN 50178
Dimensions (W x H x D) mm 35 x 90 x 101
Weight kg 0.1 0.1 0.11
Mounting Top-hat rail IEC/EN 60715, 35 mm
Mounting position Vertical
Ambient mechanical conditions
Protection type (IEC/EN 60529, EN50178, VBG 4) IP20 IP20 IP20
Vibrations (IEC/EN 61131-2:2008)
Constant amplitude 3.5 mm Hz 5 … 8.4 5 … 8.4 5 … 8.4
Constant acceleration, 1 g Hz 8.4 … 150 8.4 … 150 8.4 … 150
Mechanical shock resistance (IEC/EN 60068-2-27)
semi-sinusoidal 15 g/11 ms
Shocks 9 9 9
Drop to IEC/EN 60068-2-31 Drop
height
mm 50 50 50
Free fall, packaged (IEC/EN 60068-2-32) m 0.3 0.3 0.3
Electromagnetic compatibility (EMC)
Overvoltage category II II II
Pollution degree 2 2 2
Electrostatic discharge (IEC/EN 61131-2:2008)
Air discharge (Level 3) kV 8 8 8
Contact discharge (Level 2) kV 4 4 4
Electromagnetic fields (IEC/EN 61131-2:2008)
80-1000 MHz V/m 10 10 10
1.4 - 2 GHz V/m 3 3 3
2 - 2.7 GHz V/m 1 1 1
Radio interference suppression (SmartWire-Darwin) EN 55011 Class A
Burst (IEC/EN 61131-2:2008, Level 3)
Supply cables kV 2 2 2
Signal cables kV 1 1 1
SmartWire-Darwin cables kV 1 1 1
Surge (IEC/EN 61131-2:2008, Level 1) – Supply cables 0.5 kV –
Radiated RFI (IEC/EN 61131-2:2008, Level 3) V 10 10 10
Ambient climatic conditions
Operating ambient temperature (IEC 60068-2) °C -25 … +55 -25 … +55 -25 … +55
Condensation Prevent with suitable measures
Storage °C -40 - 70 -40 - 70 -40 - 70
Relative humidity, non-condensing (IEC/EN 60068-2-30) % 5 … 95 5 … 95 5 … 95
SmartWire-Darwin network
Station type SmartWire-Darwin station (slave)
Baud rate detection Automatic
SmartWire-Darwin status LED Green
Connection Plug, 8 pole
Connection plug: Device plug SWD4-8SF2-5
Current consumption (15 V SWD supply) ￫Page 19
Connection supply and I/O
Terminal type Push-in terminals
Solid mm2 0.2 - 1.5 (AWG 24 - 16)
Flexible with ferrule mm2 0.25 - 1.5 0.25 - 1.5 0.25 - 1.5
Minimum length 8 mm
24 V DC supply for output supply
Rated operational voltage Ue V – 24 DC -15 % / +20 % –
Input voltage residual ripple % – ≦ 5 –
Protection against polarity reversal – Yes –
