Darwin Technology
SWD DIL module, SWD PKE module, SWD NZM interface
2010 CA08103002Z-EN
1/27
Operation mode
Manual/automatic mode No Yes Yes –
Setting – Rotary switch Rotary switch –
Connection auxiliary contact
Number 2 2 – –
Rated voltage Ue V DC 15 15 – –
Self-supplied Self-supplied – –
Input current at 1 signal, typical mA 3 3 – –
Potential isolation No No – –
Cable length m ≦2.8 ≦2.8 – –
Terminal type Push-in terminals Push-in terminals – Push-in terminals
Terminal capacity
Solid mm2 0.2 - 1.5 (AWG 24 - 16) 0.2 - 1.5 (AWG 24 - 16) 0.2 - 1.5 (AWG 24 - 16) 0.2 - 1.5 (AWG 24 - 16)
Flexible with ferrule mm2 0.25 - 1.5 0.25 - 1.5 0.25 - 1.5 0.25 - 1.5
Minimum length 8 mm Minimum length 8 mm Minimum length 8 mm Minimum length 8 mm
DIL-SWD-32-001 DIL-SWD-32-002 PKE-SWD-32 NZM-XSWD-704
