Darwin Technology

SWD input/output modules

2010

CA08103002Z-EN

1/23

Digital inputs

Number

8

4

4

Input current

mA

Normally 4 at 24 V DC

Voltage level to IEC/EN 61131-2

Limit value type 1

Low < 5 V DC; High > 15 V DC

Input delay

High → Low typ. < 0.2 ms

Low → High typ. < 0.2 ms

SmartWire-Darwin status

LED

Yellow

Digital semiconductor outputs

Number

–

4

–

Output current

A

–

Normally 0.5 at 24 V DC –

Short-circuit tripping current

A

–

Max. 1.2 over 3 ms

–

Lamp load

R

LL

W –

≦ 3

–

Overload proof

–

Yes, with diagnostics

–

Switching capacity

–

EN 60947-5-1 utilization

category DC-13

–

Relay outputs

Number

–

–

2

Contact type

–

–

Normally open contact

Operations

Utilization category AC-1, 250 V, 6 A

–

–

> 6 x 10

4

Utilization category AC-15, 250 V, 3 A

–

–

> 5 x 10

4

Utilization category DC-13, 24 V, 1 A

–

–

> 2 x 10

5

Safe isolation according to EN 50178

V AC

–

–

230

Minimum load current

mA

–

–

100

mA , 12 V DC

Response/reset time

ms

–

–

5/2.5

Bounce duration

ms

–

–

Normally 1.5

Short-circuit protection

–

–

External 4 A gL/gG

Status display outputs

LED

–

Yellow

Yellow

Potential isolation

Inputs from SmartWire-Darwin

Yes

Yes

Yes

Semi-conductor outputs from SmartWire-Darwin

–

Yes

–

Semi-conductor outputs from inputs

–

No

–

Relays from SmartWire-Darwin

–

–

Yes

Relays from inputs

–

–

Yes

Relays from relays

–

–

Yes

EU5E-SWD-8DX

EU5E-SWD-4D4D

EU5E-SWD-4D2R
