1/26 Darwin Technology
SWD DIL module, SWD PKE module, SWD NZM interface
2010 CA08103002Z-EN
SWDDILmodule,SWDPKEmodule,SWDNZM interface
DIL-SWD-32-001 DIL-SWD-32-002 PKE-SWD-32 NZM-XSWD-704
General
Standards IEC/EN 61131-2
EN 50178
IEC/EN 60947
Dimensions (W x H x D) mm 45 x 38 x 76 45 x 38 x 76 45 x 38 x 76 35 x 90 x 101
Weight kg 0.04 0.04 0.04 0.1
Mounting on DILM7 … DILM38 on DILM7 … DILM38 on DILM7 … DILM32 Top-hat rail I
EC/EN 60715, 35 mm
Mounting position as DILM7 … DILM38 as DILM7 … DILM38 as DILM… DILM32 Vertical
Ambient mechanical conditions
Protection type (IEC/EN 60529, EN50178,
VBG 4)
IP20 IP20 IP20 IP20
Vibrations (IEC/EN 61131-2:2008)
Constant amplitude 3.5 mm Hz 5 … 8.4 5 … 8.4 5 … 8.4 5 … 8.4
Constant acceleration, 1 g Hz 8.4 … 150 8.4 … 150 8.4 … 150 8.4 … 150
Mechanical shock resistance
(IEC/EN 60068-2-27)
semi-sinusoidal 15 g/11 ms
Shocks 9 9 9 9
Drop to IEC/EN 60068-2-31 Drop
height
mm 50 50 50 50
Free fall, packaged (IEC/EN 60068-2-32) m 0.3 0.3 0.3 0.3
Electromagnetic compatibility (EMC)
Overvoltage category II II II II
Pollution degree 2 2 2 2
Electrostatic discharge
(IEC/EN 61131-2:2008)
Air discharge (Level 3) kV 8 8 8 8
Contact discharge (Level 2) kV 4 4 4 4
Electromagnetic fields
(IEC/EN 61131-2:2008)
80 - 1000 MHz V/m 10 10 10 10
1.4 - 2 GHz V/m 3 3 3 3
2 - 2.7 GHz V/m 1 1 1 1
Radio interference suppression
(SmartWire-Darwin)
EN 55011 Class A EN 55011 Class A EN 55011 Class A EN 55011 Class A
Burst (IEC/EN 61131-2:2008, Level 3)
Supply cables kV – – – 2
CAN/DP bus cable kV 1 1 1 1
SmartWire-Darwin cables kV 1 1 1 1
Radiated RFI (IEC/EN 61131-2:2008,
Level 3)
V 10 10 10 10
Ambient climatic conditions
Operating ambient temperature
(IEC 60068-2)
°C -25 … +60 -25 … +60 -25 … +60 -25 … +55
Condensation Prevent with suitable
measures
Prevent with suitable
measures
Prevent with suitable
measures
Prevent with suitable
measures
Storage °C -30 - 70 -30 - 70 -30 - 70 -40 - 70
Relative humidity, non-condensing
(IEC/EN 60068-2-30)
% 5 … 95 5 … 95 5 … 95 5 … 95
SmartWire-Darwin network
Station type SmartWire-Darwin
station (slave)
SmartWire-Darwin
station (slave)
SmartWire-Darwin
station (slave)
SmartWire-Darwin
station (slave)
Address setting Automatic Automatic Automatic Automatic
Status SmartWire-Darwin LED Green/orange Green/orange Green/orange Green
Connections Plug, 8 pole Plug, 8 pole Plug, 8 pole Plug, 8 pole
Plug connectors Device plug
SWD4-8SF2-5
Device plug
SWD4-8SF2-5
Device plug
SWD4-8SF2-5
Device plug
SWD4-8SF2-5
Current consumption (15 V SWD supply) ￫Page 19
