AccessoriesDevice plug Network terminator Coupler
SWD4-8SF2-5 SWD4-RC8-10 SWD4-8SFF2-5
Housing bushing plug Housing bushing socket
SWD4-SM8-20 SWD4-SF8-20
Switch cabinet bushing plug Switch cabinet bushing socket
SWD4-SM8-20 SWD4-SFL8-20
Adapter for blade terminal to round cable Plug connector for SWD round cables, straight
SWD4-8FRF-10 SWD4-SF8-67 SWD4-SM8-67
Plug connector for SWD round cables, angled
SWD4-SF8-67W SWD4-SM8-67W
