Darwin Technology

SWD gateways, power feeder modules

2010

CA08103002Z-EN

1/21

Supply voltage U

Pow

Supply voltage

V

24

DC -15 % + 20 % 24 DC -15 % + 20 % –

24

DC -15 % + 20 %

Input voltage residual ripple

%

≦ 5

≦ 5

–

≦ 5

Protection against polarity reversal

Yes

Yes

–

Yes

Rated operational current

I

A

0.7

0.7

–

0.7

Overload proof

Yes

Yes

–

Yes

Inrush current and length

A

12.5

A/6 ms

12.5

A/6 ms

–

12.5

A/6 ms

Heat dissipation at 24 V DC

W 3.8

3.8

–

3.8

Potential isolation between U

Pow

and 15 V

SmartWire-Darwin supply voltage

No

No

–

Yes

Bridging voltage dips

ms

10

10

–

10

Repeat rate

s

1

1

–

1

Status indicator

LED

Yes

Yes

–

Yes

Provision of SmartWire-Darwin supply voltage

Rated operational voltage

U

e

V

14.5

± 3 %

14.5

± 3 %

–

14.5

± 3 %

Max. current

I

max

A

0.7

0.7

–

0.7

If SWD modules with a total power consumption > 0.7 A are connected, a power feeder

module EU5C-SWD-PF2 has to be used.

Short-circuit rating

Yes

Yes

–

Yes

Connection supply voltages

Terminal type

Push-in terminals

Solid

mm

2

0.2 - 1.5 (

AWG 24 - 16)

Flexible with ferrule

mm

2

0.25 - 1.5

0.25 - 1.5

0.25 - 1.5

0.25 - 1.5

SmartWire-Darwin network

Station type

SmartWire-Darwin master

–

–

Number of SmartWire-Darwin slaves

58

99

–

–

Baud rate

kBd

125

125

–

–

Address setting

Automatic

Automatic

–

–

Status indicator

LED

SmartWire-Darwin master LED: green

Configuration LED: red

–

–

Connections

Plug, 8 pole

2

x plug, 8 pole

Plug connectors

Blade terminal SWD4-8MF2

2

blade terminals SWD4-8MF2

Fieldbus interface

Function

PROFIBUS-DP slave CANopen slave

–

–

Bus protocol

PROFIBUS-DP

CANopen

–

–

Baud rate

Up to 12 MB

Up to 1 MB

–

–

Baud rate detection

Automatic

Automatic

–

–

Station address

2 … 125

2 … 32

–

–

Address setting

DIP switches

DIP switches

–

–

Status indication of fieldbus interface

LED

Two-colored red/

green

Two-colored red/

green

–

–

Terminal resistor

Switchable via plug DIP switches

–

–

Terminal type fieldbus

1

x SUB-D, 9 pole,

socket

1

x SUB-D plug,

9

pole

–

–

Potential isolation

Yes

Yes

–

–

EU5C-SWD-DP

EU5C-SWD-CAN EU5C-SWD-PF1-1 EU5C-SWD-PF2-1
