Technical data
EU5C-SWD-DP EU5C-SWD-CAN EU5C-SWD-PF1-1 EU5C-SWD-PF2-1
General
Standards IEC/EN 61131-2
EN 50178
Dimensions (W x H x D) mm 35 x 90 x 127 35 x 90 x 124
Weight kg 0.16 0.16 0.11 0.17
Weight g – – – –
Mounting Top-hat rail IEC/EN 60715, 35 mm
Mounting position Vertical
Ambient mechanical conditions
Protection type (IEC/EN 60529, EN50178, VBG 4) IP20 IP20 IP20 IP20
Vibrations (IEC/EN 61131-2:2008)
Constant amplitude 3.5 mm Hz 5 … 8.4 5 … 8.4 5 … 8.4 5 … 8.4
Constant acceleration, 1 g Hz 8.4 … 150 8.4 … 150 8.4 … 150 8.4 … 150
Mechanical shock resistance (IEC/EN 60068-2-27)
semi-sinusoidal 15 g/11 ms
Shocks 9 9 9 9
Drop to IEC/EN 60068-2-31 Drop
height
mm 50 50 50 50
Free fall, packaged (IEC/EN 60068-2-32) m 0.3 0.3 0.3 0.3
Electromagnetic compatibility (EMC)
Overvoltage category II II II II
Pollution degree 2 2 2 2
Electrostatic discharge (IEC/EN 61131-2:2008)
Air discharge (Level 3) kV 8 8 8 8
Contact discharge (Level 2) kV 4 4 4 4
Electromagnetic fields (IEC/EN 61131-2:2008)
80-1000 MHz V/m 10 10 10 10
1.4 - 2 GHz V/m 3 3 3 3
2 - 2.7 GHz V/m 1 1 1 1
Radio interference suppression (SmartWire-Darwin) EN 55011 Class A
Burst (IEC/EN 61131-2:2008, Level 3)
Supply cables kV 2 2 2 2
CAN/DP bus cable kV 1 1 – –
SmartWire-Darwin cables kV 1 1 1 1
Surge (IEC/EN 61131-2:2008, Level 1)
Supply cables/CAN/DP bus cable Supply cables 0.5 kV, CAN/DP bus cable 1 kV
10
Radiated RFI (IEC/EN 61131-2:2008, Level 3) V 10 10 10 10
Ambient climatic conditions
Operating ambient temperature (IEC 60068-2) °C -25 … +55 -25 … +55 -25 … +55 -25 … +55
Condensation Prevent with suitable measures
Storage °C -40 - 70 -40 - 70 -40 - 70 -40 - 70
Relative humidity, non-condensing (IEC/EN 60068-2-30) % 5 … 95 5 … 95 5 … 95 5 … 95
Supply voltage UAux
Rated operating voltage V 24 DC -15% +20%
Input voltage residual ripple % ≦ 5 ≦ 5 ≦ 5 ≦ 5
Protection against polarity reversal Yes Yes Yes Yes
Max. current Imax A 3 3 3 3
If contactors with a total power consumption > 3 A are connected, a power feeder module
EU5C-SWD-PF1/2 has to be used.
Short-circuit rating no, external fuse FAZ Z3
Heat dissipation W Normally 1 Normally 1 Normally 1 Normally 1
Potential isolation No No No No
Rated operating voltage of 24 V DC stations V Normally UAux - 0.2 Normally UAux - 0.2 Normally UAux - 0.2 Normally UAux - 0.2
