1/24 Darwin Technology
SWD RMQ connections
2010 CA08103002Z-EN
SWDRMQconnections
M22-SWD-K11 M22-SWD-KC11 M22-SWD-LED-…
General
Standards IEC/EN 61131-2
EN 50178
IEC/EN 61131-2
EN 50178
IEC/EN 61131-2
EN 50178
Dimensions (W x H x D) mm 12 x 42 x 39 12 x 45 x 37 10 x 42 x 45
Weight g 10 10 10
Mounting position Any Any Any
Ambient mechanical conditions
Protection type (IEC/EN 60529, EN50178, VBG 4) IP20 IP20 IP20
Vibrations (IEC/EN 61131-2:2008)
Constant amplitude 3.5 mm Hz 5 … 8.4 5 … 8.4 5 … 8.4
Constant acceleration, 1 g Hz 8.4 … 150 8.4 … 150 8.4 … 150
Mechanical shock resistance (IEC/EN 60068-2-27)
semi-sinusoidal 15 g/11 ms
Shocks 9 9 9
Drop to IEC/EN 60068-2-31 Drop
height
mm 50 50 50
Free fall, packaged (IEC/EN 60068-2-32) m 0.3 0.3 0.3
Electromagnetic compatibility (EMC)
Overvoltage category Not applicable Not applicable Not applicable
Pollution degree 2 2 2
Electrostatic discharge (IEC/EN 61131-2:2008)
Air discharge (Level 3) kV 8 8 8
Contact discharge (Level 2) kV 4 4 4
Electromagnetic fields (IEC/EN 61131-2:2008)
80-1000 MHz V/m 10 10 10
1.4 - 2 GHz V/m 3 3 3
2 - 2.7 GHz V/m 1 1 1
Radio interference suppression (SmartWire-Darwin) EN 55011 Class A EN 55011 Class A EN 55011 Class A
Burst (IEC/EN 61131-2:2008, Level 3)
Supply cables kV 2 2 2
SmartWire-Darwin cables kV 1 1 1
Radiated RFI (IEC/EN 61131-2:2008, Level 3) V 10 10 10
Ambient climatic conditions
Operating ambient temperature (IEC 60068-2) °C -30 … +55 -30 … +55 -30 … +55
Condensation Prevent with suitable measures
Storage °C -40 - 80 -40 - 80 -40 - 80
Relative humidity, non-condensing (IEC/EN 60068-2-30) % 9 … 95 9 … 95 9 … 95
SmartWire-Darwin network
Station type SmartWire-Darwin station (slave)
Number – – –
Baud rate setting Automatic Automatic Automatic
SmartWire-Darwin status LED Green Green Green
Connections Plug, 8 pole Plug, 8 pole Plug, 8 pole
Plug connectors SWD4-8SF2-5 M22-SWD-I…LP SWD4-8SF2-5
Number of insertion cycles ≥ 50 ≥ 50 ≥ 50
Current consumption (15 V SWD supply) ￫Page 19
Function element
Contacts 1 changeover
contact
1 changeover
contact
–
Lifespan mechanical/electrical Switch
opera-
tions
1 x 106 1 x 106 –
LED display LED No No Yes
Diagnostics Yes Yes No
Fixing Front fixing Base fixing Front fixing
