23 / 36
Darwin Technology
Current consumption SWD slaves
2010
CA08103002Z-EN
www.eaton.com1/19
CurrentconsumptionSWD slaves
Engineering
SWDgateways,power feedermodules
Current consumption 15 V SWD supply voltage
Part no.
Article no.
Current consumption
Notes
mA
M22-SWD-K11
115964
7
-
M22-SWD-K22
115965
7
-
M22-SWD-LED-W
115966
19
-
M22-SWD-LED-B
115967
19
-
M22-SWD-LED-G
115968
19
-
M22-SWD-LED-R
115969
19
-
M22-SWD-K11LED-W
115972
19
-
M22-SWD-K11LED-B
115973
19
-
M22-SWD-K11LED-G
115974
19
-
M22-SWD-K11LED-R
115975
19
-
M22-SWD-K22LED-W
115978
19
-
M22-SWD-K22LED-B
115979
19
-
M22-SWD-K22LED-G
115980
19
-
M22-SWD-K22LED-R
115981
19
-
M22-SWD-KC11
115995
7
-
M22-SWD-KC22
115996
7
-
M22-SWD-LEDC-W
115997
19
-
M22-SWD-LEDC-B
115998
19
-
M22-SWD-LEDC-G
115999
19
-
M22-SWD-LEDC-R
116000
19
-
M22-SWD-K11LEDC-W
116003
19
-
M22-SWD-K11LEDC-B
116004
19
-
M22-SWD-K11LEDC-G
116005
19
-
M22-SWD-K11LEDC-R
116006
19
-
M22-SWD-K22LEDC-W
116009
19
-
M22-SWD-K22LEDC-B
116010
19
-
M22-SWD-K22LEDC-G
116011
19
-
M22-SWD-K22LEDC-R
116012
19
-
DIL-SWD-32-001
118560
40
-
DIL-SWD-32-002
118561
40
-
PKE-SWD-32
126895
58
-
EU5E-SWD-8DX
116381
12
-
EU5E-SWD-4D4D
116382
45
-
EU5E-SWD-4D2R
116383
45
-
NZM-XSWD-704
135530
35
-
M22-SWD-I1-LP01
115990
17
With terminating resistor switched on
M22-SWD-I2-LP01
115991
17
M22-SWD-I3-LP01
115992
17
M22-SWD-I4-LP01
115993
17
M22-SWD-I6-LP01
115994
17
SWD4-RC8-10
116020
17
-
Power consumption/current consumption 24 V SWD control voltage U
AUX
DIL-SWD-32-… PKE-SWD-32
Pick-up power
for DILM(C) 7-9, DILA
W
3
3
for DILM(C) 12-15, DILMP20
W
4.5
4.5
for DILM(C) 17-38, DILMP32-45
W
12
12
Pick-up current
for DILM(C) 7-9, DILA
mA
125
125
for DILM(C) 12-15, DILMP20
mA
188
188
for DILM(C) 17-38, DILMP32-45
mA
500
500
Sealing power
for DILM(C) 7-9, DILA
W
3
3
for DILM(C) 12-15, DILMP20
W
4.5
4.5
for DILM(C) 17-38, DILMP32-45
W
0.5
0.5
Sealing current
for DILM(C) 7-9, DILA
mA
125
125
for DILM(C) 12-15, DILMP20
mA
188
188
for DILM(C) 17-38, DILMP32-45
mA
21
21
