PowerSafe – Commercial & Industrial 81
Residual Current Circuit Breakers (RCCBs)
General Characteristics
Standard Conformity IEC 60947-3
Rated Current (In) A 40A - 63A, 80 - 125A
Rated Voltage (ac) (Ue) V 240/415
Rated Frequency (f) Hz 50
Nos. of Poles (Execution) 2P, 3P, 4P
Utilization Category AC 22A
Rated Insulation Voltage (Ui) V 660
Rated Impulse Voltage (Uimp) kV 4
Electrical / Mechanical Endurance Nos
(No. of operations) 10000
Ambient Temperature 0C -5 to +55
Terminal Capacity (Max) 25
Vibration g 5
Protection Class IP-20
Installation Position Vertical / Horizontal
Mounting Clip on DIN Rail
(35mm x 7.5mm)
Case & Cover Moulded, flame retardant
thermoplastic material
Cable Capacity
2P - 35mm2, 3P & 4P - 50mm2
Max. Torque - 3Nm
763, 763,
2 Pole
