83 / 100
00=100 kWh/kVArh
000= 1000 kWh/kVArh
ulsewidth 200/100/60ms.RelayRating 240V ac50mA
.5.2 RS485 Output for Modbus RTU
orModbusRTU, the followingRS485 communication
arameters canbe configured from the set-upmenu:
aud rate 1200, 2400, 4800, 9600,
arity none /odd / even
S485 network address 3-digit number, 1 to 247
odbus
™
Wordorder Hi/Lobyteorder issetautomatically to
ormalor reverse. Itcannotbeconfigured from the set-upmenu.
.6 Reference Conditions of
Influence Quantities
nfluenceQuantities are variables that affectmeasurement
rrors to aminordegree.Accuracy is verified under nominal
alue (within the specified tolerance)of these conditions.
23°C±1°C
50or 60Hz±2%
Sinusoidal (distortion
factor< 0·005)
Terrestrial flux
PowerSafe – Commercial & Industrial
83
FRAME
SIZE
PART NO BS88 REF
Busmman
Reference
Lawson
Reference
Fuse Fixing
Centres
Tag Type
1
LSEDF201SN
A2
AAO 2A - 20A
TIA 2A - 20A
73mm
OFFSET
LSDEF203N
LSEDF321SN
AAO 2A - 32A
TIA 2A - 32A
LSEDF323N
2
LSEDF631SN
A3
AAO 2A-32A,
BAO 40A -63A
TIA 2A-32A,
TIS 40A -63A
73mm
LSEDF633N
LSEDF633SN
3
LSEDF1001SN
A4
CEO 32A - 100A TCP 32A - 100A
94mm
(Max Barrel Dia
31mm)
LSEDF1003N
LSEDF1003SN
LSEDF1251N
CEO 32A - 100A,
DEO 125A
TCP 32A - 100A,
CTFP 125A
LSEDF1253N
LSEDF1253SN
4
LSEDF1603N
B2
DD 80 - 160 A
TF 80 - 160A
111MM
Centre
LSEDF1603SN
LSEDF2003N
DD 80 - 200A
TF 80 - 200A
LSEDF2003SN
LSEDF2503N
B3
DD 80 - 200A,
ED 250A
TF 80 - 200A, TKF
250A
LSEDF2503SN
LSES2503N
LSES2503SN
5
LSEDF4003N
B4
ED 250A - 400A TMF 315A - 400A
111MM
(Max Barrel dia
50mm)
LSEDF4003SN
LSES4003N
LSES4003SN
FRAME SIZE Rating (A)
Lug size
(Max.) Cu.
Lugs (mm
2
)
Thread
Size
Terminating
Tightening
Torque (Nm)
Recommended Fuse BS type
Frame 1
20-32
6/10*
M6
3.7
A2
Frame 2
63
16/25*
M6
3.7
A3
Frame 3
100
35/50*
M8
9
A4
125
50/70*
M8
9
A4
Frame 4
160
70/95*
M10
48
B2
200
95/150*
M10
48
B2
250
120/185*
M10
48
B2
Frame 5
400
240/300*
M10
48
B4
*Based on cable spreader boxes fitted
Fuse Comparison Chart
Installation Data
