HAVELLS
96 x 96 Panel Mounted Energy Meter (PS3 Quickwire) Specification
Input
Nominal input voltage
100-289V AC L-N (173-500V AC L-L)
Max. continuous input overload voltage
OF NOMINAL
Max. short duration voltage
2 x range maximum (1 second application input repeated 5 times at 5 minute intervals)
Nominal input voltage burden
< 0.2VA per phase
Nominal input current
5A AC rms
Max. continuous input
OF NOMINAL
overload current
Max. short duration input current
10 x nominal (1 second application repeated 5 times at 5 minute intervals)
Frequency
45-66Hz
Auxiliary
Operating range
6 !# NOMINAL
6 !# ABSOLUTE LIMITS OR
6 $#
(96-420V DC absolute limits)
Accuracy
Voltage (V)
Current (A)
Neutral current calculated (A)
Frequency (Hz)
0.1 Hz
Power factor (PF)
OF UNITY
Active power (W)
OF RANGE
Reactive power (VAr)
OF RANGE
Apparent power (VA)
OF RANGE
Active energy (kWh)
Class 1 (IEC 62053-21)
Reactive energy (kVArh)
OF RANGE
THD
UP TO ST HARMONIC
Response time
1sec
Output modules (optional)
1 per module
Pulsed output relays
(2 modules fitted per Ci3)
Contact rating
50mA max at 250V AC
Type
Solid state relay
RS485 ModbusTM
1 ModbusTM channel per module
output module
(maximum of 1 module fitted per Ci3)
Type
2-wire half duplex
Baud rate
2400, 4800, 9600, 19200, 38400
Enclosure
DIN 96 panel mount
Enclosure style
96x96x64.1mm (depth behind panel without module 58mm, with module 82.5mm)
Dimensions
92x92mm
Panel cut-out
1-5mm (1-3mm when used with IP65 cover)
Panel thickness
IP52
Front protection rating
IP30
Case protection rating
Polycarbonate to UL94V0
Material
300g
Weight
Shrouded screw-clamp 0.05-4mm wire
Terminals
Environment
Operating temperature
-10°C to +55°C
Storage temperature
-20°C to +70°C
Relative humidity
NON CONDENSING
Shock
30g in 3 planes
Vibration
10Hz to 50Hz
Dielectric voltage
Withstand test 3.25kV rms 50Hz for 1 minute between comms and measuring inputs,
comm and aux, aux and measuring inputs
