HAVELLS
Frame
AAN
No. of Poles
1P/3P/4PwSN
Standard current range / rating (I
n
)
A
25-250*
Thermal release setting (Adjustable)
OF L
n
Magnetic release setting for current rating:
25A - 63A
400A
80A - 125A
800A
160A - 250A
1600A
Rated ultimate short circuit
breaking capacity (lcu), KA
(at different voltages)
(25-125A)
(25-250A)
240V
50
40
415V
35
25
440V
35
25
500V
25
18
LCS
LCU
Weight SP (Single Pole)
Kg
0.7
TP (Triple Pole)
Kg
1.8
FPwSN (Four Pole
Switched Neutral)
Kg
2.4
Terminal capacity (cable)
Sq.mm70 (upto 100A)/150 (125A-250A)
Bus bar (width)
Sq.mm25 (125A-250A)
Recommended Torque
Nm
10
AAN Frame
Standard conformity :
IEC 60947-2
Rated operational voltage :
500V AC
Rated Insulation Voltage :
750V AC
Type of release :
Thermomagnetic
Utilisation Category :
A
Rated frequency :
50/60 Hz
Ambient temp :
40oC (50oC on request)
Operating altitude :
2000 meters
(UMIDITY
Rated impulse voltage :
8 KV
Cable capacity
Tunnel Terminals: 150mm2
Moulded Case Circuit Breakers (MCCBs)
