References
Motion control modules for stepper motors
Description
For control of
Connections
on connectors
No. of
axes
Reference
Weight
kg
15-
way SUB-D 20-way HE10
Motion control
modules for stepper
motors
Lexium 32C/M servo
drive or translator
with RS 422 I/O,
5
V
c
TTL inputs
and 5 V
c
TTL open
collector outputs
Lexium 32C/M
servo drive or
translator I/O
Auxiliary I/O,
24
V
c
power
supply
1
TSX CFY 11
0.440
2
TSX CFY 21
0.480
Connection accessories
Description
Connect on TSX
CFY
p
1
connector
Type of connector on
TSX CFY
p
1
module
No.
(1)
Unit
reference
Weight
kg
SUB-D connectors
Sold in lots of 2
Lexium 32C/M
servo drive or
translator I/O
15-
way SUB-D
(1
per axis)
2
TSX CAP S15
0.050
Modicon Telefast
ABE7 connection
sub-base
Auxiliary I/O for axes
0/1, 24
V
c
power
supply
20-
way HE10
(1
for 2 axes)
ABE 7H16R20
0.300
Additional terminal
block
Order in multiples of 5
20
linked terminals
for ABE 7H16R20
sub-base
–
ABE 7BV20
0.060
(1)
For numbers, see page 4/31.
TSX CFY 11
TSX CFY 21
References
Presentation:
page 4/30
Architectures:
page 4/31
Modicon Premium automation
platform
TSX CFY 11/21 motion control modules for
stepper motors
ABE 7H16R20
