Safety automation solutions
Preventa configurable safety controllers
Type XPS MC
Presentation
XPS MC16ZC
XPS MC32ZC
Presentation
Configurable safety controllers XPS MC
pp
Z
p
are designed to provide a solution
for safety applications requiring conformity to Performance Level PL e/Category
4
in accordance to standard EN/ISO 13849-1 and SIL 3 requirements of standard
EN/IEC 61508.
The range of configurable safety controllers comprises 6 products, each with different
technical characteristics.
Configurable
controllers
Safety
inputs
Safety
outputs
(1)
Communication via
CANopen bus Profibus bus Modbus serial
link
XPS MC16Z
16
6
+ 2 x 2 –
–
Yes, slave
XPS MC16ZC
16
6
+ 2 x 2 Yes, slave –
Yes, slave
XPS MC16ZP
16
6
+ 2 x 2 –
Yes, slave Yes, slave
XPS MC32Z
32
6
+ 2 x 2 –
–
Yes, slave
XPS MC32ZC
32
6
+ 2 x 2 Yes, slave –
Yes, slave
XPS MC32ZP
32
6
+ 2 x 2 –
Yes, slave Yes, slave
Line control
The safety inputs are supplied by the various control outputs
(2)
,
in such a manner
so as to monitor for short-circuits between the inputs, short-circuits between each
input and earth or the presence of residual voltages.
The controller, assisted by the control outputs, continuously tests all the connected
inputs. As soon as an error is detected on an input, all the outputs associated with this
input are disconnected. Safety outputs associated with other inputs remain active.
Configuration
Safety controllers XPS MC
pp
Z
p
are configurable and addressable using software
XPS MCWIN running on a PC. Connection accessories required: see page 4/13.
Connections
For connection of safety inputs and outputs, safety controllers XPS MC
pp
Z
p
can be
fitted with a choice of:
v
screw connectors type XPS MCTS
pp
,
or
v
spring clip connectors type XPS MCTC
pp
.
These connectors are to be ordered separately, see page 4/13.
(1) 8
independent safety outputs = 6 solid-state safety outputs + 2 x 2 relay outputs (4 relay
outputs with guided contacts).
(2) 8
control outputs are available but they are not safety outputs.
