Safety automation solutions
Preventa configurable safety controllers
Type XPS MC
References
(
continued)
References
Connecting cables
(1)
Function
Length
m
Reference
Weight
kg
Diagnostics using Magelis operator dialogue terminal type XBT GT
3
VW3 A8 306 R30
1.130
Configuration software
1
Adaptor: RJ45 socket/PC connection cables –
XPS MCCPC
0.011
2
Cable to PC serial port (type SUB-D9)
2.5
TSX PCX 1031
0.170
3
Straight shielded twisted pair cables,
EIA/TIA 568 standard
(
RJ45 connector at each end)
2
490
NTW 000 02
–
5
490
NTW 000 05
–
12
490
NTW 000 12
–
Straight shielded twisted pair cables,
UL and CSA 22.1 approved
(
RJ45 connector at each end)
2
490
NTW 000 02U
–
5
490
NTW 000 05U
–
12
490
NTW 000 12U
–
with
RJ45/PC USB port converter
(2)
0.4
TSX CUSB485
–
Function
Medium
Length
m
Reference
Weight
kg
Modbus serial link access
Premium automation platform TSX SCY 21601 –
XPS MCSCY
–
CANopen bus access
1
CANopen connection cables
(
fitted with: 1 SUB-D 9-pin female connector
at each end)
0.3
TSX CANCADD03
–
1
TSX CANCADD1
–
3
TSX CANCADD3
–
5
TSX CANCADD5
–
2
CANopen tap-off box
–
TSC CANTDM4
–
3
Standard CANopen cables
50
TSX CANCA50
–
100
TSX CANCA100
–
300
TSX CANCA300
–
Profibus bus access
100
TSX PBS CA100
–
400
TSX PBS CA400
–
Accessories
(1)
Regulated switch mode
power supply, single-phase
Output voltage: 24…28.8 V
c
Nominal current: 10 A
Nominal power: 240 W
ABL 8RPS24100
1.000
(1)
To be ordered separately.
(2)
The converter
TSX CUSB485
is installed using
Driver Pack V2.3
.
This "driver" is available on the Safety Suite V2 software
or downloadable from our site:
www.schneider-electric.com.TSX PCX 1031
XPS MCCPC
490
NT
p
000
pp
ABL 8RPS24100
TSX CAN TDM4
TSX CUSB485
