Safety automation solutions
Preventa configurable safety controllers
Type XPS MC
Presentation
(
continued)
Safety functions
Configuration of the safety functions is carried out using software XPS MCWIN
which is available on the Safety Suite V2 CD-ROM.
30
certified safety functions
are available with this software and they are easily
assignable to the safety outputs. The safety functions have multiple combination
possibilities and various starting conditions.
The safety functions are:
v
certified in accordance with EN/ISO 13849-1 and IEC 61508,
v
configurable in controller XPS MC using software XPS MCWIN which is available
on the Safety Suite V2 software pack.
All 8 safety outputs are suitable for use in safety related parts of control systems
conforming to Performance Level PL e/Category 4 in accordance to EN/ISO 13849-1.
Main safety functions
b
Emergency stop monitoring, with or without time delay, 1 or 2-channel wiring
b
Two-hand control (type III-C conforming to EN 574/ISO 13851)
b
Guard monitoring with 1 or 2 limit switches
b
Guard monitoring for injection presses and blowing machines
b
Magnetic switch monitoring
b
Sensing mat monitoring
b
Light curtain (type 4 conforming to EN/IEC 61496, relay or solid-state output)
monitoring
b
Zero speed detection
b
Dynamic monitoring of hydraulic valves on linear presses
b
Monitoring safety stop at top dead centre on eccentric press
b
Safety time delays
b
“
Muting” function of light curtains
b
Enabling switch monitoring, 2 or 3 contact
b
Hydraulic press
b
Eccentric press
b
Foot switch monitoring
b
Chain shaft breakage monitoring
b
Position selector
Application schemes and functional diagrams
See instruction sheet on
www.schneider-electric.com1
