Modicon Premium automation
platform
Preventa safety module type TSX PAY 262
References
TSX PAY 262
ABE 7CPA13
TSX CPP
p
02
TSX CPP301
Safety module
Type of input
c
24
V
Safety outputs Connections
Reference
Weight
kg
12
Emergency stops or limit
switches (double or single
contacts),
1
reset button,
1
feedback loop,
1
reset monitor
2
N/O
(
volt-free)
2.5
A (Ithe)
Inputs: 44-way SUB-D connector
Outputs: screw terminal
(
supplied)
TSX PAY 262
0.430
Connection accessory
Description
For
connection on
screw terminal
Type of connector on
TSX PAY 262
Reference
Weight
kg
Modicon Telefast ABE 7
sub-base
for TSX PAY 262 module
Safety system,
reset, monitoring
and loop inputs
Power supply
c
24
V
SUB-D, 44-way
ABE 7CPA13
0.290
Connecting cordsets
Use
From
TSX PAY 262
module
To
Length
Reference
Weight
kg
For fast wiring
44-
way SUB-D
connector
ABE-7CPA13
sub-base
1
m
TSX CPP 102
0.160
2
m
TSX CPP 202
0.260
3
m
TSX CPP 302
0.360
For standard wiring
44-
way SUB-D
connector
Flying leads
with colour-
coded wires
3
m
TSX CPP 301
0.330
