References
Counter modules
Type of input
Characteristics
No. of
channels
Reference
Weight
kg
24
V
c
2/3
wire PNP/NPN sensors,
5
V
c
RS 422 or 10…30 V
c
Totem
Pole incremental encoders
40
kHz counting
Cycle time 5 ms
2
TSX CTY 2A
0.320
40
kHz counting
Cycle time 10 ms
4
TSX CTY 4A
0.430
Connection accessories
Description
For connecting Connector type on
TSX CTY
pp
No.
(1)
Unit reference Weight
kg
SUB-D connectors
Sold in lots of 2
Counter sensors or
incremental encoder
15-
way SUB-D
4
TSX CAP S15
0.050
Modicon Telefast
ABE 7
connection
sub-bases
Counter sensors
and 24 V
c
power
supply
15-
way SUB-D
–
ABE 7CPA01
0.300
Auxiliary inputs,
24
V
c
power
supply and
5
V/10…30 V
c
encoder power
supply
20-
way HE 10
(
for 2 channels)
–
ABE 7H16R20
0.300
Additional terminal
block
Order in multiples of 5
20
linked terminals
for ABE 7H16R20
sub-base
–
ABE 7BV20
0.030
Connection
interfaces for
incremental encoder
5
V
c
RS 422
encoder
15-
way SUB-D
2
TSX TAP S15 05
0.260
10...30
V
c
Totem
Pole encoder
15-
way SUB-D
2
TSX TAP S15 24
0.260
(1)
For numbers, see page 4/17.
References
TSX TAP S15
pp
TSX CTY 2A
TSX CTY 4A
ABE 7CPA01
ABE 7H16R20
Presentation:
page 4/16
Operation:
page 4/17
Modicon Premiumautomation
platform
TSX CTY 2A/4A counter modules
