References
(
continued)
Modicon Premiumautomation
platform
TSX CTY 2C measurement and counter module
References
(
continued)
Connecting cables
Description
From TSX CTY 2C
module
To
No.
(1)
Length Reference
Weight
kg
Cordsets
AWG 12 (0.205 mm
2
)
15-
way
SUB-D
connector
ABE 7CPA01/CPA11
sub-bases or
TSX TAP S15
pp
accessory (15-way SUB-D
connector)
5
0.5
m
TSX CCP S15 050
0.110
1
m
TSX CCP S15 100
0.160
2.5
m
TSX CCP S15
0.300
20-
wire preformed
cables
AWG 22 (0.324 mm
2
)
500
mAmax.
24
V
c
power supply
and 5 V/10…30 V
c
encoder power supply
auxiliary inputs
(
moulded 20-way
HE 10 connector)
Free end with
colour-coded wires
7
3
m
TSX CDP 301
0.400
5
m
TSX CDP 501
0.660
10
m
TSX CDP 1001
1.210
Rolled ribbon cables
AWG 28 (0.08 mm
2
)
100
mAmax.
24
V
c
power supply
and 5 V/10…30 V
c
encoder power supply
auxiliary inputs
(20-
way HE 10
connector)
ABE 7H16R20 sub-base
(
HE 10 20-way
connector)
8
1
m
TSX CDP 102
0.090
2
m
TSX CDP 202
0.170
3
m
TSX CDP 302
0.250
Connecting cables
AWG 22 (0.324 mm
2
)
500
mAmax.
24
V
c
power supply
and 5 V/10…30 V
c
encoder power supply
auxiliary inputs
(
moulded 20-way
HE 10 connector)
ABE 7H16R20 sub-base
(
HE 10 20-way
connector)
8
0.5
m
TSX CDP 053
0.085
1
m
TSX CDP 103
0.150
2
m
TSX CDP 203
0.280
3
m
TSX CDP 303
0.410
5
m
TSX CDP 503
0.670
10
m
TSX CDP 1003
1.180
(1)
For numbers, see page 4/21.
TSX CCP S15
ppp
TSX CDP
p
01
TSX CDP
p
02
TSX CDP
p
03
Presentation:
page 4/20
Architectures:
page 4/21
