88 / 413
4/22
TSX CTY 2C
ABE 7CPA01
TSX TAP S15
pp
ABE 7H16R20
References
References
Measurement and counter module
Type of input
Characteristics
No. of channels Reference
Weight
kg
24
V
c
2/3
PNP/NPN wire sensors,
5
V
c
RS 422 or 10…30 V
c
Totem Pole
incremental encoders
SSI serial or parallel output absolute
encoders with ABE 7CPA11 sub-base
Counting
Cycle time 1 ms
2
TSX CTY 2C
0.340
Connection accessories
Description
For connecting
Connector type on
TSX CTY 2C
No.
(1)
Unit reference Weight
kg
SUB-D connector
Sold in lots of 2
Counter sensors or
incremental encoder
15-
way SUB-D
6
TSX CAP S15
0.050
Modicon Telefast
ABE 7 connection
sub-bases
Counter sensors and
24
V
c
power supply
15-
way SUB-D
–
ABE 7CPA01
0.300
Auxiliary inputs,
24
V
c
power supply
and 5 V/10…30 V
c
encoder power supply
20-
way HE 10
(
for 2 channels)
–
ABE 7H16R20
0.300
Additional terminal
block
Order in multiples of 5
20
linked terminals for
ABE 7H16R20
sub-base
–
–
ABE 7BV20
0.060
Adaptor sub-base for
TSX CTY 2C
module
(2)
5
V
c
, 10…30
V
c
parallel output absolute
encoders
15-
way SUB-D
–
ABE 7CPA11
0.300
Connection
interfaces for
incremental encoder
5
V
c
RS 422 encoder 15-way SUB-D
4
TSX TAP S15 05
0.260
10...30
V
c
Totem Pole
encoder
15-
way SUB-D
4
TSX TAP S15 24
0.260
(1)
For numbers, see page 4/21.
(2)
Enables multiplexing of 2 absolute encoders on the same channel (up to 4 absolute encoders when using 2
ABE 7CPA11
adaptor sub-bases).
Modicon Premiumautomation
platform
TSX CTY 2C measurement and counter module
Presentation:
page 4/20
Architectures:
page 4/21
