References
Electronic cam module
Type of input
Characteristics
No. of
axes
Reference
Weight
kg
Incremental encoder
Supplied with 5 V or 10…30 V,
with RS 422/485 or 5 V Totem Pole outputs
(1)
500
kHz counting with
incremental encoder
1
TSX CCY 1128
0.480
Absolute encoder
RS 485 serial or parallel
(2)
200
kHz sampling with
serial absolute encoder
Connection accessories
Description
For connection of
Connector type on
TSX CCY 1128
No.
(3)
Unit reference
Weight
kg
SUB-D connector
Sold in lots of 2
SSI absolute/
incremental encoder
15-
way SUB-D
4
TSX CAP S15
0.050
Modicon
Telefast ABE 7
adaptor sub-base
Absolute encoder with
parallel outputs
(16
to 24 bits) 5 V,
10…30
V
c
15-
way SUB-D
–
ABE 7CPA11
0.300
Modicon
Telefast ABE 7
connection sub-base
Auxiliary inputs,
5…24
V
c
encoder
power supply
20-
way HE 10
(1
per module)
–
ABE 7H16R20
0.300
Track outputs
20-
way HE 10
(1
for 2 groups)
Additional terminal
block
Order in multiples of 5
20
linked terminals for
ABE 7H16R20
sub-base
–
–
ABE 7BV20
0.060
Connection
interfaces for
incremental encoder
5
V
c
RS 422/RS 485
encoder
15-
way SUB-D
6
TSX TAP S15 05
0.260
10…30
V
c
Totem
Pole encoder
15-
way SUB-D
6
TSX TAP S15 24
0.260
(1)
TotemPole encoder with additional Push/Pull outputs.
(2)
Absolute encoders with parallel outputs require the
ABE 7CPA11
adaptor interface.
(3)
Numbers (see page 4/25).
TSX TAP S15
pp
Presentation:
page 4/24
Architectures:
page 4/25
References
TSX CCY 1128
ABE 7CPA11
ABE 7H16R20
Modicon Premium automation
platform
TSX CCY 1128 electronic cam module
