C-14
Front panels
Door, W = 650/800 mm
DD380582
DD380583
Designation
Cat. no.
Plain door
W
= 650 mm
08516
W
= 800 mm
08518
Transparent door
W
= 650 mm
08536
W
= 800 mm
08538
reversible for left or right-hand opening
equipped with a handle and keylock (key 405).
For other possibilities, see page C-25.
Note:
the 800 mm door is supplied with a 150 mm barrier for the side compartment, plus a
finishing accessory to improve the appearance of the upright.
b
b
08536.
08538.
DD380580
DD380581
Cover frame
Designation
Cat. no.
Cover frame
W
= 400 mm
08574
(1)
W
= 650 mm
08576
(2)
W
= 800 mm (650 +150)
08578
(3)
(1)
Replaces catalogue number
08554
.
(2)
Replaces catalogue number
08556
.
(3)
Replaces catalogue number
08558
.
secured using four screws.
Note:
for 800 mm wide frameworks, the 650 mm frame is supplied with a plain wicket door,
150 mm wide.
b
08576
(1)
.
08578
(3)
.
Door, W = 300/400 mm.
DD380584
DD380602
Designation
Cat. no.
Plain door
W
= 300 mm
08513
W
= 400 mm
08514
Transparent door
W = 400 mm
08534
Door with cut-out
W
= 300 mm
08593
W
= 400 mm
08594
reversible for left or right-hand opening
equipped with a handle and keylock (key 405).
For other possibilities, see page C-25.
Note:
fhe door with cut-out can be equipped with front plates for 72 x 72 or 96 x 96 instruments,
see page A-68.
b
b
08513.
08593.
