PVC-U perimeter trunking systems
PVC-U PERIMETER TRUNKING SYSTEMS
www.marshall-tufflex.comMono Plus 20 trunking
| 113
Dividing fllet option for
centre compartment
Smallest 3
compartment
trunking option
that accepts
standard power,
voice and data
accessories
Three segregated
compartments
Mono Plus 20 is an economical and stylish
three-compartment trunking, compact in size
and designed to fit within areas that may
have trunking height restrictions.
Product information
•
140 x 50mm
•
1 main compartment and 2 smaller outer compartments
•
Can be subdivided
•
Suitable for dado application
Data information
•
Standard bend radius 25mm
•
Data fttings available for bend radius up to 50mm
•
Adjustable data box 32-40mm
•
Screened divider and data boxes
PAGE
107
Coupler
code
pack
EC20WH
5
End cap
code
pack
EEC20WH
5
Internal bend
code
pack
EIB20WH
5
External bend
code
pack
EXB20WH
5
Flat angle – up/down
code
pack
EFA20WH
1
Fabricated
Slow bend
code
pack
EFA20SBWH
1
Fabricated
Trunking base
code
pack
EMT20WH
4 x 3m
Main compartment cover
code
pack
ETL1WH
8 x 3m
Basic components
Fittings
Part M
For box assemblies that
meet the requirements
of Part M (DDA) please
refer to page 106.
Standard colour
WH
WH
: White
antimicrobial trunking
‘Biooption’available
tospecialorder
p272
Technical
Information
Single
Cover
