PVC-U perimeter trunking systems
PVC-U PERIMETER TRUNKING SYSTEMS
www.marshall-tufflex.comCompact 1 is a small, fully segregated two compartment
trunking system with a chamfered top profile. This
trunking is suited to fit within areas where physical
outside dimensions are important, for example,
to negotiate above or below radiators and window sills.
Product information
•
130 x 50mm
•
1 full and 1 half size compartment
•
For dado installation
•
Can be subdivided
Compact 1
Internal bend assembly
code
description pack
ELIBCD1WH
assemblies
1
EIBCD1WH
covers only
1
Compact 1
External bend assembly
code
description pack
EL0BCD1WH
assemblies
1
Compact 1 trunking
| 117
Basic components
Fittings
Data information
•
Standard bend radius 25mm
•
Data fttings available for bend radius up to 50mm
•
Compact 1 and 2 small compartment can be screened against
EMI with no reduction in cable capacity
•
Adjustable data box 32-40mm
•
Screened divider and data boxes
•
Steel divider available
Dividing fllet option for
large compartment
Separate access to
each compartment
Compact 1
Couplers
code
description pack
ECC1WH
2 piece
5
ECHC1WH
1 piece
5
Compact 1
End caps LH & RH
code
description pack
EECC1LHWH
2 piece
5
EECC1RHWH
2 piece
5
EECHC1LHWH
1 piece
5
EECHC1RHWH
1 piece
5
Part M
For box assemblies that
meet the requirements
of Part M (DDA) please
refer to page 106.
Angled cover
Standard colour
WH
WH
: White
Compact 1
flat tees
Compact 1 flat
tees are handed
to the left or to
the right side.
For the product
you require,
please order the
following:
Left upward
=EFTC1ULWH
Left downward
= EFTC1DLWH
Right upward
= EFTC1URWH
Right downward
= EFTC1DRWH
For further
advice please
call the Technical
Team on +44
(0)1424 856688.
Base unit
code
pack
ETB2WH
4 x 3m
Main compartment cover
code
pack
ETL1WH
8 x 3m
Angled cover
code
pack
ETAC1WH
8 x 3m
Compact 1
Internal bend
code
description pack
EIBC1WH
2 piece
5
EIBHC1WH
1 piece
5
Compact 1
External bend
code
description pack
EXBC1WH
2 piece
5
EXBHC1WH
1 piece
5
Compact 1
Flat angle upward
code
pack
EFAC1UWH
1
Compact 1
flat angle downward
code
pack
EFAC1DWH
1
